Supplier: | Mustech Electronics Co., Ltd |
---|---|
Price: | US $ 40/Piece |
Min Order: | 1/Piece |
Quantity:: | |
Trade Terms: | FOB,EXW,CIF |
![]() |
Prod Model: | H809P |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Email Alert: | Yes, by Sending Captured Photos Via Email |
FTP Alert: | Yes, by Sending Captured Photos to Preset FTP |
By Micro-SD Card: | Yes, Record Plan Can Be Set |
Supported OS: | Microsoft Windows XP/Vista/7/8 |
Display Resolution: | 720p (1280*720p) |
Audio Input: | Built-in Microphone / One Channel Audio Input |
Audio Output: | One Channel Audio Output (Earphone Jacket) |
Wireless Standard: | IEEE 802.11b/G |
Manage Software: | PC (Windows), Ios, Android |
Pan/Tilt Angle: | Pan: 350-Degree, Tilt: 120-Degree |
Certification: | RoHS |
HDMI Format: | 720P |
Effective Distance: | 0-9m |
Remote Control: | With Remote Control |
Type: | IP Camera |
Sensor: | CMOS |
Style: | Mini Camera |
Feature: | Mini Size |
Technology: | Wireless |
Model No. | 809P | |
Image Sensor | Image Sensor | 1/4" CMOS Sensor |
Display Resolution | 720P (1280*720P) | |
Lens | f: 6mm, F:2.0, Built-in IR Filter | |
Minimum Lux Required | 0.5lm for Normal Operation | |
Lens | Lens Type | Glass Lens |
Viewing Angle | 60degree | |
Audio | Input | Built-in Microphone / One Channel Audio Input |
Output | One Channel Audio Output (earphone jacket) | |
Audio Compression | ADPCM | |
Video | Image Frame Rate | 20fps(720P), 30fps(QVGA) |
Resolution | 1280x720 (720P), 640x480(VGA), 320x240(QVGA) | |
Flip Mirror Images | Vertical / Horizontal | |
Frequency | 50Hz, 60Hz, Outdoor | |
Video Parameters | Brightness, Contrast | |
Communication | Ethernet Interface | Built-in 10/100Mbps, Auto MDI/MDIX, RJ-45 |
Supported Protocol | HTTP, FTP, TCP/IP, UDP, SMTP, DHCP, PPPoE, DDNS, UPnP, GPRS | |
Wireless Standard | IEEE 802.11b/g | |
Data Rate | 802.11b: 11Mbps (Max.), 802.11g: 54Mbps (Max.) | |
Wireless Security | WEP & WPA WPA2 Encryption | |
Physical | Pan/Tilt Angle | Pan: 350-Degree, Tilt: 120-Degree |
Alarm Input | One Channel On/Off Input | |
Alarm Output | One Channel On/Off Output | |
Infrared Light | LED Illuminators for Night Vision | |
Alarm Features | Motion Detection | Yes |
Email alert | Yes, by sending captured photos via email | |
FTP alert | Yes, by sending captured photos to preset FTP | |
Storage | By Micro-SD card | Yes, record plan can be set |
Manage Software | App | iOS, Android |
Software | PC (Windows) | |
PC Hardware Requirements | CPU | 2.0GHZ or Above (Suggested 3.0GHz) |
Memory | 256MB or Above (Suggested 1.0GB) | |
Display Card | 64Mor Above | |
Supported OS | Microsoft Windows XP/Vista/7/8 | |
Power | Power Supply | DC12V/2.0A |
Power Consumption | 7 Watts (Max.) | |
Environment | Operating Temp. | 0- 55(14°F - 131°F) |
Operating Humidity | 20% - 85% Non-Condensing | |
Storage Temp. | -10- 60(14°F – 140°F) | |
Storage Humidity | 0% - 90% Non-Condensing |
