Shaanxi HAVEN Equipment Co., Ltd. >> My Series Hydruaulic Surface Grinding Machine

My Series Hydruaulic Surface Grinding Machine

Name: My Series Hydruaulic Surface Grinding Machine
Brand: china-manufacturer-directory.com
SKU: 320008072
Availability: InStock
Rating: 4.6 (102 reviews)

Supplier:	Shaanxi HAVEN Equipment Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,EXW

Product Specifications

Prod Model:	MY7130/7132A/7140A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Surface Grinding Machine:	320X1000mm
Type:	Surface Grinding Machine
Processing Object:	Curve
Controlling Mode:	Artificial
Automatic Grade:	Semiautomatic
Precision:	Precision

Product Description

Hydraulic surface grinding machine:

1, Compact structure and easy operate.
2, Table longitudinal movement by hydraulic.
3, Table trantsverse feed by automation operate or by handle.
4, Grinding head vertical move can be adopted with power rapid movement or hand micro feed.

model		unit	MY1230
Table Size		mm	750×300
Max.longitudinal travel of the table		mm	780×320
Max.area to be ground		mm	780×310
Max.distance of table surface to spindle center		mm	550
Slide-way of Table			Double V-type rail
The Speed of Longitudinal travel		m/min	3-20
Feed of Cross Handwheel	per revolution	mm	2.5
	per graduation		0.02
The Speed of cross travel	Off and On	mm/min	1-20
	Continual		50-500
Feed of Vertical Handwheel	per revolution	mm	2
	per graduation		0.01
The Speed of Vertical Travel		mm /min	600
Wheel Speed		50HZ	1450
Wheel Size WA46K5V			250×25×76
Power of Spindle motor		Kw	2.2
Hydraulic station motor		Kw	2.25
Working Pressure		Mpa	4
Max.Runoff		L/min	18
The Capacity of Fuel Tank		L	80
Coolant Pump		W	40
Net weight of Machine		kg	1300
Gross weight		kg	1430
Machine Size		M	1.88×1.48×1.85
Packing Size		M	1.91×1.50×2.03

Technical Parameters			Unit		MY1224		MYS1224
Max.workpiece to be Ground ( L×W×H)			mm		630×310×390		630×310×390
Max. Grinding Length			mm		630		630
Max. Grinding Width			mm		320		320
Distance From Table Surface To Spindle Center			mm		550		550
Slide way					V-type rail with Steel-ball		V-type rail with Steel-ball
V-type rail with Steel-ball			Kg		200		200
Table Size (L×W)			mm		600×300		600×300
Number of T -Slot			mm×n		14×1		14×1
V-type rail with Steel-ball (Grinding Length/Width)			m/min		3-20		3-20
Cross Feed On Handwheel			mm		0.02/Graduation 2.5/revolution		0.02/Graduation 2.5/revolution
Vertical Feed On Handwheel			mm		0.01/Graduation 1.25/revolution		0.01/Graduation 1.25/revolution
Wheel Size (dia×width×bore )			mm		200×20×31.75		200×20×31.75
Spindle Speeds	50Hz	rpm		2850		2850
				0-6000		30-6000
Totale Power			Kw		3.79		2.5
Spindle Motor			Kw		2.2		2.2
Working Pressure			Mpa		3		3
Max.Capacity			L/min		20		20
Minimum Of Numerical			L		80		80
Surface Roughness			μm		Ra0.63		Ra0.63
Paraller Level			mm		300:0.005		300:0.005
Machine Size (L×W×H)			mm		1900×1530×1830		1900×1530×1830
Packing Size (L×W×H)			mm		1980×1530×2030		1980×1530×2030
Gross,Net			T		1.2,1.33		1.1,1.2

We, Shaanxi Haven Equipment Co., Ltd, is consisted with 2 factories and 1 international trading company, so we can export our products directly at competitive price. To run our business conveniently, we set up our 2 factories in Nantong Industry Zone which is located in the most developed economic area in China and is nearby the Shanghai Sea Port, that will be much helpful to low our export cost.
With experienced engineers and worker, we produce high quality machines and supply good after sale service. In the past years, we are specialized in import and export of machinery and equipment such as machine tools, vehicles maintenance equipments, motors, bearings, hand tools, power tools and industrial materials. Our business scope also includes import and export of technology, contracting overseas projects and engineer training services.
Our products have been exported to more than 30 countries or regions in the world with high quality, We commit ourselves to cooperating with importers and exporters all over the world. We are looking forward to your enquiries and collaboration. Our technicians will assure you of appropriate equipment with reasonable prices and best pre-sale and after-sale services.
Our Business Scope Include: Turning Machines (Lathe), Drilling Machines, Drilling And Milling Machines, Boring Machines, Milling Machines, Machining Centers, Grinding Machines, Tool Grinding Machines, Gear Cutting And Finishing Machines, Planning Machines, Shaping Machines, Slotting Machines, Broaching Machines, Sawing Machines, Cut-Off Machines, Screwing And Threading Machines, Honing Machine, Polishing Machines, Shearring Machines, Press Brakes, Bending Machine, Punching Machine, Iron Worker, Presses, Rolling Machine, Notching Machine, Engraving Machines, Electric Discharging Machine (EDM), etc.
Our target is: High quality, efficient service, reliable honesty.
Management System Certification: ISO 9001,ISO 9000
International Commercial Terms: FOB, CFR, CIF
Terms of Payment: LC, T/T
Average Lead Time: Peak season lead time: one monthOff season lead time: within 15 workdays
Number of Foreign Trading Staff: 11~20 People
Export Year: 2003-09-09
Export Percentage: >90%
Main Markets: South America, Eastern Europe, Southeast Asia, Africa, Mid East
Factory Address: No. 31Nan Er Huan East Road, Xi'An, China
R&D Capacity: Own Brand(HAVEN)
No. of R&D Staff: 11-20 People
No. of Production Lines: 3
Annual Output Value: US$10 Million - US$50 Million
