Product Specifications
| Prod Model: |
E5071B |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
The HP / Agilent E5071B ENA RF Network Analyzer dramatically improves measurement accuracy and responds to current and future test needs. Because it performs up to 125 dB 2 wide dynamic range at 10 Hz IFBW, the sweep speed can be faster at the required dynamic range. The trace noise is lowered to 0.001 dB RMS at 3 kHz IFBW. It delivers accurate pass band ripple measurement of a filter. The ENAs excellent measurement performance improves test quality and repeatability as well as test throughput, which affect production yield and the overall cost of test.
The HP / Agilent E5071B ENA RF Network Analyzer perform fast and accurate RF component measurements for both R&D evaluations and production testing. The Agilent E5071B (300 kHz to 8.5 GHz) model offers integrated 2, 3, or 4 test ports, and enable various component measurements from 2-port filters to multiport devices like duplexers and couplers. The ENA offers built-in balanced measurements, matching circuit simulation, and port characteristic impedance conversion. In addition, the ENA provides frequency-offset and harmonics measurement capabilities. These functions increase engineering efficiency by delivering fast and accurate measurement results for the most advanced RF components, such as balanced SAW filters, differential amplifiers, mixers, converters, and front-end modules.
