New Arrival Perimeter Infrared Beam Sensor

Name: New Arrival Perimeter Infrared Beam Sensor
Brand: china-manufacturer-directory.com
SKU: 740315165
Availability: InStock
Rating: 4.4 (92 reviews)

Price:	US $ 15.3-17pair
Trade Terms:	FOB,EXW
Min Order:	10pair
Pay Type:	T/T,Money Gram,Western Union

Contact Supplier

Showroom Product Company Profile

Photoelectric Active Infrared Beam Detector

Function:

1. Wired and BUS system compatible, holographic spot real-time report
2. Using the solid power charger of no longevity ending, low voltage and mini power consumption.
3. Adopts DSP chip, patented multi-dimensional mistake-corrective code, true detection alarm technology
4. The digital ambiguous artificial intelligent recognition: Four band frequency and use the artificial intelligent ambiguous judgment reduce the false alarm rate to zero.
5. Intelligent power emission. Adjustment the emission power of the beams automatically, it prolong the tube's longevity and reduce the power consumption.
6. Green environment protection: With the controllable function display, after test, closes the display; It can save power a lot.
7. Two sets of independence precession mini adjustment inner build optical aiming lens.
8 Full function of self diagnose, environment self adjustment, troubles locked.
9 Patent equivalent checking, special digital filter wave, its anti-interference of light arrive at IP85.
10. The upper and nether optical lens adjust at the same time, enable the adjustment quicker and more exact.

FAQ

1. Warranty
Normally the alarm panel will be 2 years,accessories will be 1 years.

2. Why choose us?
As the professional manufacturer in home security system with 14years experience, we developed series of alarm system with high quality and competitive price. In first business, sample order is available. With professional R&D team to provide OEM&ODM service.

3. When can I get the price?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us by 18219119414

4. Are your samples free or need cost?
It can be free, but anyway we have to charge for the samples first, the sample charge can be returned after official order placed.

5. How can I get your samples
You're welcomed to email us for checking. It will be ready for delivery in 3-7 days after payment. The samples will be sent to you by express.

Technical Specification:

Model	ABE-100	ABE-150	ABE-200	ABE-250
Outdoor alert distance	100m	150m	200m	250m
Indoor alert distance	300m	450m	600m	750m
Number of beams	3
Response time	35_700ms
Alarm output	NC&NO contact rating AV/DC 30V/0.5A
Alarm output-BUS	MA BUS constact rating AV/DC 30V/0.5A
Working current	65mA	65mA	65mA	70mA
Working voltage	DC 13.8_24V;AC 11_18V
Long life mode	32mA	32mA	32mA	40mA
Temperature	-25 centigrade to 55 centigrade
Humidity	5%_95% (RH)
BUS output	RS-485
Tamper output	NC contact rating AV/DC 24V/0.5mA
Horizontal adust	180°(±90°)
Vertical adjust	±10°
Case material	PC

Prod Model:	ABE-100/150/200/250
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Appearance:	Black Case
Response Time:	50-700ms
Case Material:	PC
Type:	Industry Alarm
Application:	Outdoor
Signal Transmission:	Wired Alarm
Working Mode:	Active
Sensor Type:	Infrared Alarm
Working Principle:	Electro-Optical Type
Certification:	CE, CE & RoHS

We guaranteed products at a competitive price and high quality. At present, our products have a very good sale in domestic and overseas market. We wish to cooperate with you to create a bright future and mutual benefit. Much appreciation for your prompt attention in advance, we are eager to look forward to hearing from you soon.
