Product Specifications
| Prod Model: |
Q2403-16 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Port: 8: |
Weight: 3.5kg |
| Color: Black: |
Warranty: One Year |
| Transmission Rate: |
1024Kbps |
| Interface Type: |
USB |
| Type: |
External |
Product Description
Dear customer: About the SMS modem, we have four itmes, different item different function and of course different price, we have wavecom modem with Q2303, Q2403, Q2406, Q24Plus.
Q2303 support SMS. 900/1800MHz
Q2403 support SMS and MMS. 900/1800MHz
Q2406 support SMS, MMS and TCP protocol. 900/1800MHz
Q24plus suport SMS, MMS and EDGE. 850/900/1800/1900MHz
Before buying, pls check carefully the function, if you not find the url of the product which you want to buy, pls contact me freely! What is more, below the description there is the url for each item for you reference, pls check. Any queries, pls contact me freely! Candy here hope you have a nice shopping!
8 USB GSM Bulk SMS MMS Modem Description:
The device built-in 8 wireless modules be inserted 8 SIM cards use 8 cards to send text messages. Send speed as 8 times as a single channel modem. It uses the development of WAVECOM module, 220V power supply be a long time stability, generous luxury housing. It is working compatible with windows 2008 R2, Windows 7, Vista, XP, 2006/2000, 98SE/CE, LINUX, .
Key Feature:
Just like 8 single-channel equipments work at the same time
Insert 8 SIM cards(big or small)
Connection with the computer through a data line be integrated with Serial 8
Each channel with separate power switch
Each individual module be demolished
Industrial chassis, elegant shell
GSM frequency: 900/1800 MHz
8 x SIM card(big/small) slots
Wireless access to internet
Comply with GSM phase2 standard
Dual-band/Quad-band(optional)
RS-232/USB interface(optional)
8 SIM Card supported (Big/Small)
Optional data, voice function
Send and receive English SMS in bulk
Basic Feature:
Asynchronous, transparent or non-transparent, to a maximum 14400 bits / s
Baud Rate: 300-115200 bits / s
Automatic baud rate: From 2400 to 19200 bits / s
Fax support three
Switched voice and fax
V. 42, V. 42bis
GPRS compatible
WAP compatible
SMA Antenna Interface
SIM Card Outlet
Power connector
RS-232, the Mini-dB-9 connector
AT command control ( GSM 07.07 and 07.05)
Application:
Large shopping malls, supermarkets
Professional market, large wholesalers
Large hotels, large-scale entertainment
Large agencies
Transport, logistics industry
Large enterprises, and institutions
Large hospitals, large bookstore
Newspaper, television and radio stations
Oil Company ( other chain business model)
Government agencies or large township
Hardware Feature:
Support dual-band GSM: 900/ 1800 MHz
Meet the ETSI GSM 2 + standards
Class 4 ( 2W @ 900 MHz) Class 5 ( 1W @ 1800 MHz)
5 -24 VDC power supply (which be directly connected to the nickel- metal
Hydride or lithium batteries)
Operating Temperature: -20 ° C - + 55 ° C
Storage temperature: -25 ° C - + 70 ° C
Size: Standard 1U chassis
