Product Specifications
| Prod Model: |
MX-A3013 New |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Weight: |
0-100Kg |
| Type: |
Hydrostatic Head Tester |
| Oil Cylinder Position: |
No |
| Power Source: |
AC 110V/220V |
Product Description
Used for determining accurately and swiftly the resistance of fabrics (coated, uncoated & non woven) and films to water penetration under pressure while firmly clamped in the test rig of standard area, by means of dynamic test method and static test method.
The bank is linked to a test head to which the specimen is clamped quickly and stably by means of a hand wheel.
After starting the hydrostatic pressure test, the test pressure is automatically controlled; hydrostatic head test result is digitally displayed.
The test specimen is observed visually for evidence of penetration by water.
The test area is well illuminated and an unobstructed observation of the sample is from all sides greatly facilitates the visual drop detection. 100cm2 hydrostatic head is included
Specifications:
5 test methods are included
Pressure range:
0-200kPa(2, 000cmH2O, or 2 bar), 0-500kPa
Holding force:
5, 000N
Increasing rate of water pressure:
1-30kPa/min, or 1~100kPa/min (for the capacity of 500kPa)
Accuracy:
0.2% F. S
Units:
Pa, kPa, mmHg, cmH2O
Specimen holder:
100cm2 (7.8cm2 optional)
Power/air sources:
220/110V, 50/60Hz, 3A
Dimensions(WxDxH):
650x320x320
Weight:
45kg/100lb
Standards:
ISO 811, ISO 1420, FZ/T 01004, GB/T 4744
