Product Specifications
| Prod Model: |
(YDL-invisiable 120x60 60W) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Invisiable 3014 SMD LED Panel Light: |
600*600mm Dimension 60W |
| LED Chip: |
Epistar/Samsung/Lumensmax |
| Wide Beam Angle: |
120degree |
| OEM/ODM: |
Is Available |
| Delivery Time: |
3-7working Day |
| Power Consumption: |
60W |
| Working Temperature: |
-20 - 50degree |
| Lamp Luminous Efficiency(Lm/W): |
70lm-90lumen/W |
| LED Quantity: |
300PCS 3014 SMD LEDs |
| Light Source: |
LED |
| Appearance: |
Square |
| Type: |
Ceiling |
| Emitting Color: |
White |
| Certification: |
VDE |
| Housing Material: |
Acrylic |
| Base Material: |
Metal |
| Voltage: |
85V-265V |
| Dimmable: |
With Dimmable |
| Beam Angle: |
120degree |
Product Description
New type 3014 invisible LED advertising panel light 60W 4600lm 120X60CM 60X60CM
Features:
1. This smart switch use the sound wave as control source and avoid to switch frequently by manual, also it has delay switch off function.
To use audio control mode and brightness automatic detection, when the lightness below 7Lux, and if the audio signal more than 52dB± 8dB, the Panel light will be switch on automatic, and after 60s, should power off automatic and to make the energy saving.
2. Edgelite, Anodizing AL frame, PMMA LGP and diffuser, bright, soft and comfortable luminosity
3. Premium SMD LED, >60% energy saving than fluorescent lamps
4. Distinguish circuit design ensures no interference with any LEDs when a single one malfunctions
5. External high PF constant current LED driver, instant start; No flickering and no humming; Safe and reliable
6. Four sides illuminating, better heat sink, temperature rise <20deg., longer lifespan, >50, 000 hours
7. Simple and splendid appearance
8. Easy installation: Embedded (replace the grill lamp or false ceiling), mounted on the ceiling or wall or hang from the roof using chains
9. Mounted on walls as wall washer or back lighting for art drawings or advertisements
10. Bean angle: 120°
11. Certification: CE, RoHS
12.3 years warranty
Installation ways:
1. Replace the plaster ceiling
2. Suspended to the ceiling
3. Mounted on the ceiling or in the wall
Applications:
Bar, coffee house, shopping mall, hotel, restaurant, housing, office, showroom, counter, outdoor decoration, school, hospital etc.
|
Model No.: |
YDL-PL-120X60 |
|
Lamp Rated Total Power: |
60W |
|
Lamp Total Luminous Flux: |
4446-4680LM |
|
Lamp Rated Luminous Efficiency: |
85lm/w |
|
Input Voltage: |
AC 90 ~ 265 V |
|
Light Source: |
300pcs SMD LED 3014 |
|
Dimensions: |
1195*595x 9 MM |
|
IP Rating: |
IP44,IP54,IP65 |
|
Power Efficiency: |
90% |
|
Color Temperature: |
2700-3000K
4500-5000K
6000-6500k |
|
Color Rendering Index(CRI): |
Ra>80 |
|
Frequency Range: |
50 ~ 60 Hz |
|
Storage Temperature: |
-40deg ~ 70deg; 0% ~ 100% R.H. |
|
Working Temperature: |
-25deg ~ 50deg; 0% ~ 100% R.H. |
|
Lamp Body Material: |
Aluminum, PMMA LGP, PC diffuser |
|
Beam Angle: |
120° |
|
Power Factor(PF): |
0.9 |
|
Net Weight: |
7.8kg/piece |
|
Gross Weight: |
9kg/piece |
|
Package Size(mm): |
128CM X 63CM X 4CM 9KG |
