Product Specifications
| Prod Model: |
SK |
| Markets: |
South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Q235B Carbon Steel Plate or as Client Requirement |
| Installation: |
Supplier Dispatch Engineer |
| Voltage: |
380 V Others |
| Power(W): |
5.5-110 Kw |
| Dimension(L*W*H): |
Different Model Different |
| Weight: |
6- 300 Ton |
| Certification: |
CE, ISO9001:2000 |
| Warranty: |
Two Years |
| Application: |
Construction,Metallurgical,Mining Industry etc |
| Drying Temperature: |
200-1000 Degree |
| Structure: |
Rotary Type Drier |
| Operational Method: |
Continuous |
| Operation Pressure: |
Atmospheric Dryer |
| Movement Way: |
Fixed |
| Heating Mode: |
Hot Air |
Product Description
New type professional coal slime dryer/coal slime drying machine manfucturer
coal slime dryer special characteristics:
1.This new type coal slime dryer is new environmental protection product, saving
energy and reducing loss of lignite coal.
2.coal slime dryer can improve the calorific value of lignite coal , also can
desulfuration to the lignite, reduce volatile.
3.our special design coal slime dryer, investment, small footprint, and supporting
civil works less
4.with many years experience in the field of drying,our coal slime dryer with
reliable, simple operation, convenient maintenance, safe,durable and other
Superiority,have a very good market.
5.Special design of the internal structure of coal slime dryer,with special drying and moisture control, material output moisture minimum up to 5% or less, meet the
material widely.
6. Temperature of coal slime dryer can be adjust in drying process to ensure the
quality of coal slime not change.
7.Continuous work and large capacity.
coal slime dryer market outlook:
1.With implementation of the strategy of sustainable development, coal slime and
other mineral resources, the rational development and utilization has become an
important issue, the original low value the full development and utilization of coal
slurry is urgent
2.Use of valuable lignite resources, turning waste into wealth, not only can produce
considerable economic benefits
3. coal slime dryer can be dry and brown in ensuring the quality of the same
premise, reducing the sulfur content of lignite to improve the calorific value.
4.the coal slime after drying can improve combustion efficiency, we can making
more full use of coal resources
The coal slime dryer applications include:
This new type coal slime dryer also can used to drying other material,such as lignite, kaolin, dry municipal sludge, paper sludge, leather sludge, printing and dyeing
sludge, chemical materials and pharmaceutical liquid fermentation residue, food
fermentation, sugar residue, chemical organic waste, and more.
Technology data of caol slime dryer:
| Model | Diameter
(m) | Length
(m) | speed
(r/min) | Installation obliquity
(%) | Drying temperature
(°c) | Capacity
(t/h) | Motor
(kw) | Weight
(ton)
|
| Φ0.8x8 | 0.8
| 8 | 3-8 | 3-5% | ≥800 | 0.6-0.8 | 3 | 3.5 |
| Φ1.0x10 | 1.0
| 10 | 3-8 | 3-5% | ≥800 | 1-1.5 | 4 | 7 |
| Φ1.0x12 | 1.0
| 12 | 3-8 | 3-5% | ≥800 | 1.5-1.8 | 4 | 8 |
| Φ1.0x15 | 1.0
| 15 | 3-8 | 3-5% | ≥800 | 1.5-2 | 5.5 | 10 |
| Φ1.2x12 | 1.2
| 12 | 3-8 | 3-5% | ≥800 | 2-3 | 11 | 15 |
| Φ1.5x15 | 1.5
| 15 | 3-8 | 3-5% | ≥800 | 3-3.5 | 15 | 20 |
| Φ1.8x15 | 1.8
| 15 | 3-8 | 3-5% | ≥800 | 4.5-5.0 | 18,5 | 28 |
| Φ2.0x18 | 2.0
| 18 | 3-8 | 3-5% | ≥800 | 6-6.5 | 18.5 | 42 |
| Φ2.0x20 | 2.0
| 20 | 3-8 | 3-5% | ≥800 | 6.5-6.8 | 18.5 | 50 |
| Φ2.2x20 | 2.2
| 20 | 3-8 | 3-5% | ≥800 | 6.5-7.0 | 22 | 56 |
| Φ2.4x20 | 2.4
| 20 | 3-8 | 3-5% | ≥800 | 7.5-8 | 30 | 60 |
| Φ2.5x25 | 2.5
| 25 | 3-5 | 3-5% | ≥800 | 10-11 | 37 | 68 |
