Shenzhen Zenithsun Electronics Tech Co., Ltd. >> Non-Inductive Ceramic Tube Wirewound Resistor with Mounting (DQR)

Non-Inductive Ceramic Tube Wirewound Resistor with Mounting (DQR)

Name: Non-Inductive Ceramic Tube Wirewound Resistor with Mounting (DQR)
Brand: china-manufacturer-directory.com
SKU: 677596836
Availability: InStock
Rating: 4.5 (115 reviews)

Supplier:	Shenzhen Zenithsun Electronics Tech Co., Ltd.
Price:	Negotiable/Piece
Min Order:	10/Piece
Quantity::
Trade Terms:	FOB,EXW,CIF

Product Specifications

Prod Model:	DQR
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color Of The Wierowund Resistor:	Green
Material Of The Wirewound Resistor:	Ceramic Tube, Silicon
Resistance Values:	0.01r-100kr
Tolerance:	0.1%; 0.5%; 1%; 5%; 10%
Power Rating:	15W-20kw
Temperature Coefficient:	250ppm
Insulation Resistance:	500V DC
Resistance To Shock:	1.5mm 10-50-10Hz
Solding Area:	Over 95%
The Resistor Mounts:	Can Be Cancelled
Function For Resistance:	Load Resistor
Installation:	DIP Resistor
Material:	Wire-wound Resistor
Resistance:	Fixed Resistor
Package Type:	Throught Hole
Type:	Power Wireowund Resistor

Product Description

1. Copper wire or chrominum alloy wire is wound on the ceramic tube coated with non-flammable resin, good dissipation, high stability, and long life.

2. High power rating, high overload.

3. The DQR series have the beautiful outlook.

4. Widely used in power supply, transducer, elevator, arena audioand Lifting, braking, ship, load equipment, high requirement equipment industry, ect.

5. For customer specifications, can be made into variable resistor.

Zenithsun Resistors Co., Ltd. is a professional resistors manufacturer with excellent R&D, production and sales. ZENITHSUN has a great number of well-trained, pragmatic, and honest staffs. With employees' rich expreiences and creative capacity, ZENITHSUN would offer all types of power resistors with the competitive price and considerate service to the domestic and overseas manufacturers, which are in the field of transducer, elevator, jointing industry control equipments, electrical motivation or all kinds of the Hi-Fi acoustics. ZENITHSUN have prepared for all new challenge and is devoted to create a famous Chinese brand.
