Price: | US $ 1USD |
---|---|
Trade Terms: | FOB,CIF,others |
Min Order: | 1/Square Meter |
Pay Type: | L/C,T/T,Western Union |
Prod Model: | ESD-IA10S |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
RoHS, CCC, ISO9001, Fc: | All Kinds of Specifications |
Pixel Configuration: | 1R,1G,1B |
Pixel Pitch: | 10mm |
Pixel Density: | 10,000 dots / m² |
Tube Chip Color: | Full Color |
IP Rating: | IP43 |
Application: | Advertising |
Display Function: | Advertising, Video, Picture, Flash |
Certification: | CE, FCC, RoHS, UL, ETL |
1 Module Construction Description | ||||||
Each pixel contains 1 pcs 3-in-1 SMDLED Pitch 10mm, resolution: 10000dots/sqm | ||||||
2 Professional analysis | ||||||
No. | Professional analysis content | Analysis item | ||||
1 | Color matching analysis | In order to make the color matching reach the best white balance effect, the color matching rate of different color brightness is set asR : G : B = 3 : 6 : 1 | ||||
3 Pixel Parameter | ||||||
No. | Item | Parameter | ||||
1 | Pixel pitch | PH10 mm | ||||
2 | Pixel configuration | 3-in-1 SMD | ||||
4 LED Chip Parameter | ||||||
No. | Item | Wavelength | Brightness | Model No. | ||
1 | Red tube chip | 620-625nm | 400-600mcd | easter-O1 | ||
2 | Pure green tube chip | 520-525nm | 1,100-1,600mcd | easter-H1 | ||
3 | Pure blue tube chip | 465-470nm | 300-600mcd | easter -H1 | ||
For this quotation: Taiwan famous brand leds or Silan leds will be selected for the display. Quality led displays have bigger led chips for stable high brightness and prolonged lifespan. | ||||||
5 Screen Technical Parameter | ||||||
3 | Module | Pixels: 32dotsx16dots, Size: 320mm x 160mm | ||||
4 | Cabinet | Size: 1280mm x 960mm Pixels: 128dotsx 96dots | ||||
5 | Display brightness | 800CD/M 2 | ||||
6 | Brightness adjustment | 256 grade automatic, 8 grade manual | ||||
7 | Image Adjustment | Contrast, color tone, module brightness adjustable | ||||
8 | Drive Mode | Static | ||||
9 | Drive IC | MBI 5024, 16-bit processing technology | ||||
10 | View Angle | 140°horizontal, 140°vertical | ||||
11 | View Distance | 6meters~ | ||||
12 | Grey Scale | 16,384 grades | ||||
13 | Display Colors | 4.4 trillions | ||||
14 | Frame rate | ≥60 Hz | ||||
15 | Refresh rate | ≥360HZ, Guarantee the picture will not tingle when the pick up camera is kinescoping | ||||
16 | Control Mode | Synchronic control | ||||
17 | Signal Interface | DVI , S-VIDEO, CVBS, VGA, YPbPr, PAL/NTSC, HDMI, etc. through a video processor | ||||
18 | MTBF | ≥50,000 Hours | ||||
19 | Screen Lifespan | 100,000 hours | ||||
20 | Blind Spot Rate | ≤0.0002 | ||||
21 | Operating Voltage | AC 110V/220V±15%, 50-60HZ | ||||
22 | Screen Body Power Consumption | Max: 450w/M2, Average: 180w/M2 | ||||
23 | Screen body weight | About 55KG each cabinet, do not include outer frame | ||||
24 | Control Distance | 120 meters UTP CAT.6 network cable, without relay, or optical fiber transmission 500M-10,000M. | ||||
25 | System Working Environment Temperature | -40degree---+60 degree | ||||
26 | System Working environment humidity | 10%---99%RH | ||||
27 | Waterproof | IP43 | ||||
28 | System Operating Platform | WINDOWS 2000, XP, Vista | ||||
29 | Certification | ISO 9001:2000, CE, FCC, CCC, ETL, GOST |
