Product Specifications
| Prod Model: |
S(Z) 9-MS(Z) 10-MS(Z) 11-M-Phase |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Capacity: |
200,500,1000,2000,2500kVA |
| Rated Voltage Of High Voltage: |
6,6.3,10kv |
| Rated Voltage Of Low Voltage: |
0.4kv |
| Connection Symbol: |
Y,Yn0 |
| Phase: |
Three |
| Coil: |
Shell-type Transformer |
| Cooling Method: |
Oil-immersed Type Transformer |
| Winding Type: |
Multi-winding Transformer |
| Application: |
Power |
Product Description
High reliability, advanced level of performance, economic indicators and reasonable;
Using phase-shaped core of three joints, curing paint brushing the surface to reduce wear and tear and noise;
Winding structure of a new oil road design is reasonable, with the new insulation to improve the mechanical strength and the ability to engage in short-circuit;
Tank forms, beautiful, generous
Core is with advanced three steps: Vertical and horizontal and horizontal cut, lap and multi-stage. It disperses the air distribution, improve the magnetic path. Decrease the empty loading loss, current and noise.
Core with dragged panel, pressed the coil, particular glue for silicon steel; A set of measures to increase the mechanical strength.
New structure of high and low voltage wrapping, reasonable arrangement for oil tube and connection, increase the capacity of mechanical strength and anti-shortcut.
Oil box is bell type or core suspension type, the wall of oil box is as wave form.
|
TYPE |
Capacity KVA |
Load Loss |
Load Negative consu-mption |
Load
Current
|
Impedance voltage |
Dimensions |
Weight KG |
|
A |
B |
C |
D |
E |
F |
|
S9-M-30/10 |
30 |
130 |
600 |
2.1 |
4.0 |
770 |
635 |
1000 |
14 |
400 |
400 |
310 |
|
S9-M-50/10 |
50 |
170 |
870 |
2.0 |
4.0 |
1100 |
660 |
1030 |
14 |
400 |
450 |
395 |
|
S9-M-63/10 |
63 |
200 |
1040 |
1.9 |
4.0 |
1130 |
670 |
1100 |
14 |
400 |
450 |
450 |
|
S9-M-80/10 |
80 |
210 |
1250 |
1.8 |
4.0 |
1140 |
675 |
1110 |
14 |
400 |
450 |
490 |
|
S9-M-100/10 |
100 |
290 |
1500 |
1.6 |
4.0 |
1185 |
690 |
1130 |
14 |
400 |
450 |
560 |
|
S9-M-125/10 |
125 |
340 |
1800 |
1.5 |
4.0 |
1205 |
710 |
1180 |
19 |
550 |
550 |
670 |
|
S9-M-160/10 |
160 |
400 |
2200 |
1.4 |
4.0 |
1255 |
720 |
1200 |
19 |
550 |
550 |
780 |
|
S9-M-200/10 |
200 |
480 |
2600 |
1.3 |
4.0 |
1295 |
740 |
1215 |
19 |
550 |
550 |
875 |
|
S9-M-250/10 |
250 |
560 |
3050 |
1.2 |
4.0 |
1340 |
755 |
1260 |
19 |
550 |
650 |
1115 |
|
S9-M-315/10 |
315 |
670 |
3650 |
1.1 |
4.0 |
1400 |
770 |
1320 |
19 |
550 |
650 |
1280 |
|
S9-M-400/10 |
400 |
800 |
4300 |
1.0 |
4.0 |
1500 |
860 |
1400 |
19 |
660 |
750 |
1495 |
|
S9-M-500/10 |
500 |
960 |
5150 |
1.0 |
4.0 |
1575 |
895 |
1430 |
19 |
660 |
750 |
1740 |
|
S9-M-630/10 |
630 |
1200 |
6200 |
0.9 |
4.5 |
1660 |
930 |
1545 |
19 |
660 |
850 |
2110 |
|
S9-M-800/10 |
800 |
1400 |
7500 |
0.8 |
4.5 |
1830 |
1070 |
1590 |
19 |
820 |
850 |
2625 |
|
S9-M-1000/10 |
1000 |
1700 |
10300 |
0.7 |
4.5 |
1935 |
1175 |
1685 |
19 |
820 |
850 |
2860 |
|
S9-M-1250/10 |
1250 |
1950 |
12000 |
0.6 |
4.5 |
1960 |
1170 |
1730 |
19 |
820 |
850 |
3330 |
|
S9-M-1600/10 |
1600 |
2400 |
14500 |
0.6 |
4.5 |
2050 |
1220 |
1810 |
19 |
820 |
900 |
3765 |
|
S9-M-2000/10 |
2000 |
2520 |
17820 |
0.5 |
4.5 |
2030 |
1215 |
1940 |
19 |
820 |
900 |
4530 |
|
S9-2500/10 |
2500 |
2970 |
23000 |
0.5 |
5.5 |
2280 |
2070 |
2415 |
19 |
820 |
1070 |
7050 |
