Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Specifications
Cathodic protection manual rectifier
1.advanced technology
2.complete functions
3,high quality
Product usage
Suitable for aluminium and its alloy oxidation, continuous oxidation, electrolyte polish and stainless steel electrolyte polish metal surface treatment technology. It's the clean production and energy conservation and emission reduction is preferred.
Product features
1.The oil cooled special-purpose IGBT power module, with better reliability and the shell of sprayed steel plate ,
2.With the completely sealed oil immersed structure design, Significantly Improving the Performance fanticorrosion ,greatly increase the lifetime of product; The device also can be installed near the tank directly;
3.It has the constant voltage, constant current operating mode and The self-protection function of over current ,short circuit,overheating , phase lack etc .Also soft start function;
4.Standard antiseptic remote control box;
5.We can provide
1)The digital timer alarm system;
2)Ampere-hour meter;
3)RS485 or RS232 standard interface
4)4-20MA,0-5V control signal interface ,etc.(The signal interface can be customized )
Technical Parameters
Input voltage |
380V AC(Three-phase four-wire) 415V AC 50-60HZ |
Output DC current |
500-20000A Arbitrary choice |
Output DC voltage |
15V,18V,24V,36 VArbitrary choice |
Voltage stability |
≤1% |
Current stability |
≤1% |
Ripple factor |
1%-2% |
Cooling Mode |
Oil cooled |
Cooling oil |
More than 20# Transformer oil |
Efficiency |
≥90% |
workload |
Full capacity operation, more than 1,000 meters above sea level,
reduced load operation |
Work condition |
Temperature range -10 °C ~ 40 °C,Less than 90% humidity.
|
