Product Specifications
| Prod Model: |
BSZ850-1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Glass Drilling Machine |
| Certification: |
CE |
| Control System: |
PLC |
Product Description
1.1 Glass drilling machine Clamping glass in pneumatic way.
1.2 The upper drilling and nether bits bore holes one after another and feeding is automatically.
1.3 An ideal glass drilling machine, easy to operate and maintain.
| 1 | Diameter of holes | ø4~ø250mm | | 2 | Processing thickness | 3~25mm | | 3 | Maximum dimensions of workpiece | 2000x800mm | | 4 | Drilling depth | 850mm | | 5 | The total number of spindles | 2pcs | | 6 | Rotation speed of spindles | 900~3000r/min | | 7 | Voltage | 380V/50HZ(3PH4Wire) | | 8 | Drilling motor power | 2-1.5kw | | 9 | X-axis |
| | 10 | Y-axis |
| | 11 | Z-axis motor power | 2-13Nm | | 12 | Water pump | 1-250W | | 13 | Motor total power | ≈4.3kw | | 14 | Pressure of compressed air | 0.5~0.6MPa | | 15 | Table height | 820mm | | 16 | Table size | 700x700mm | | 17 | Weight | 860kg | | 18 | Overall size | 1200x1650x1630mm |
|
|
Guangdong Shunde Timbery Technology Co., Ltd. Locates in Shunde Dist, Foshan City. It is a professional and innovative glass tempering machine manufacturer with patented technologies. The glass tempering machine, with the leading energy saving technique and high quality glass tempering, has a good common evaluation by our customers.
Main products: Flat/Bending Glass Tempering Furnace, Double Chambers Tempering Furnace.
Adhering to the principle of "Quality First and Customer paramount", we provide our products with lead-edge technologies to customers.
