| Supplier: | Shenzhen Joney Security Technology Co., Ltd. |
|---|---|
| Price: | Negotiable/Piece |
| Min Order: | 1/Piece |
| Quantity:: | |
| Trade Terms: | FOB,EXW |
|
|
| Prod Model: | NVR6004L/6009L/6016L |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: | Standalone |
| Operating System: | Linux |
| Video Compression Format: | H.264(High Profile) |
| Display Image Resolution: | 720p@30fps;960p@30fps;1080P@30fps |
| Playback Image Resolution: | 720p@30fps;960p@30fps;1080P@30fps |
| Recording Mode: | Manual Recording, Motion Detection Recording, Time |
| Network Video Input: | 4CH/9CH/16CH |
| Audio Input: | No Audio |
| Alarm Input: | No Alarm |
| Realtime Playback: | 4CH 1080P Playback Simultaneously |
| System | Model | NVR-6004L/6009L/6016L |
| Main processor | High performance embedded microprocessor-31 | |
| Operating system | Embedded LINUX OS | |
| Video spec | Video compression format | H.264 |
| Display Image Resolution | 720P@30fps;960P@30fps;1080P@30fps | |
| Playback Image Resolution | 720P@30fps;960P@30fps;1080P@30fps | |
| Motion Detection | can setup 192(16×12)pcs motion detection area | |
| each channeland multi-level sensitivity(1-6 levels adjustable) | ||
| Privacy Masking | Depends on ipc | |
| Audio spec | Audio compression format | adpcm |
| Two-way audio | no | |
| Recording | Recording Mode | Manual Recording, Motion Detection Recording, Time Recording, Alarm Recording, |
| Recording storage | HDD,Network | |
| Frame rate | 30 fps | |
| Recording Playback | Max suport 4ch 1080P synchronously playback | |
| Backup Mode | Support HDD,USB Flash Disk store & backup | |
| Video | Network Video Input | 4ch/9ch/16ch |
| Video output | 1ch CVBS(BNC), 1ch VGA and 1ch HDMI | |
| Audio | Audio Input | no |
| Audio Output | no | |
| Alarm | Alarm Input | no |
| Alarm Output | no | |
| Other | Network | 1000Mbps,RJ45 port |
| RS485 | Standard 485 port,support half-duplex, green terminal port | |
| USB | 2 USB 2.0 ports | |
| HDD | support 1pcs SATA HDD inside | |
| Power | DC +12V /6A | |
| Power consumption | 20-25W(not include HDD and PoE) | |
| Operation temperature | 0-+55 | |
| Operation humidity | 10%-90% | |
| Demension | mini 1U | |
| Weight | 1.5---2KG(not include HDD) |
