Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
TC-612 optical light source can provide 850/1300nm wavelengths is for single mode fiber. Together with the TC-612 optical power meter, it is a perfect solution for the fiber optic network characterization.
1. Compact size and decent appearance
2. CW, 270Hz, 1kHz, 2kHz
3. Modulation at other wavelengths.
4. High stability of the output power
5. Backlight LCD display supports night operation
6. Large LCD, easy operation
7. Alternative 10 minutes Auto-off function conserving battery life
Applications
Maintenance in Telecom
Maintenance CATV
Fiber Optic Lab Testing
Other Fiber Optic Measurements
Features:
ModelTC-612 Optical Light Source
EmitterFP-LD
Wavelength (nm)850/1300nm (Other wavelength can be offered on request)
ConnectorFC(SC/ST as optional)
Output power>=-7dBm@1310/1550nm
Output stability(dBm)+-0.04 @20 Degree @15min
ModulationCW/270Hz/1kHz/2kHz@others
Power3PCS AAA batteries
Fiber typeSM
Working hours(h)40
Working temperature(Degree)-10~+50, 0 to 95%RH (no condensing)
Storage temperature(Degree)-20~+70, 0 to 95%RH (no condensing)
Dimension(mm)130× 63× 29
Weight (g)160
