Magnetic Separator:
Application of magnetic separator:
Permanent Cylindrical Wet Magnetic Separator
Permanent cylindrical wet magnetic separator is used for wet separation of ferromagnetic minerals and non-ferromagnetic minerals. It can work continuously with its large working clearance, good magnetic depth, and strong processing capacity. Its working principle is that when the pulps enter the magnetic zone, the ferromagnetic minerals are absorbed at the wall of the cylinder. The weekly magnetic and non-magnetic minerals are then swung off. Thus, the ferromagnetic minerals and non-ferromagnetic minerals are separated by this permanent cylindrical wet magnetic separator.
The cylinder of this permanent cylindrical wet magnetic separator can be matched with three kinds of tanks: CTS, CTN and CTD for different separation requirements. The CTS is suitable for roughing and concentrating minerals with a granularity range from 0 to 6mm. CTN is suitable for both roughing and concentrating minerals with a granularity range from 0 to 0.6mm and recycling dense media in coal preparation industry. CTD is suitable for roughing and concentrating minerals with a granularity range from 0 to 0.5mm. It is particularly suitable for concentrating of minerals with a granularity range from 0 to 0.15mm.
Working Principle of Magnetic Separator:
When the pulp flows to the tank in the magnetic separator, the mineral granules spreads under the impact of the water flow from the show pipe. As a result of the magnetic force, the magnetic minerals concentrate as a lump or a chain. This lump or chain is then absorbed on the cylinder owing to the magnetic force. When the magnetic lump or chain rotates with the cylinder, gangues and other non-magnetic minerals falls off from the lump or chain and are then discharged with the pulp. The lump or chain left at the wall of the cylinder is ore concentrate. It is then discharged off from the magnetic separator with water.
|
Model |
Magnetic Field Intensity (oe) |
Production Capacity (t/h) |
Power (kw) |
Weight (kg) |
|
CTB600x1200 |
1450 |
8-15 |
1.5 |
910 |
|
CTB600x1800 |
1500 |
15-25 |
2.2 |
1340 |
|
CTB750x1800 |
1550 |
30-45 |
3 |
2050 |
|
CTB900x1800 |
1650 |
35-60 |
4 |
3000 |
|
CTB1050x2400 |
1650 |
60-95 |
5.5 |
5020 |
|
CTB1200x3000 |
1650 |
80-150 |
7.5 |
7800 |
|
CTB1500x3000 |
1650 |
120-200 |
11 |
9600 |
Henan Dajia Mining Machinery Co., Ltd (the former Henan 3rd Machinery Factory founded in 1902) is one leading manufacturing enterprise in China and the key enterprise in mechanical industry and Zhengzhou City. After joint-stock system reform, Henan Dajia Mining Machinery Co., Ltd is established, focusing on the design and manufacture of mining machine, complete preparation equipment, rotary kiln and construction facilities, etc. With the advantages of many years' Development, we now have rich experience and powerful strength in independent design and manufacture of stone crusher, ball mill, ore separator and complete plants of cement production, limestone production and ceramsite production, and we have also passed international quality system certification.
Our products are widely applied in industries such as mining, manufacturing, mineral concentration, metallurgy, chemicals, water conservation, road and bridge constructions. Now we become the local largest manufacturer of complete ore concentration plant. With the advanced inspection equipment and strict quality guarantee system, we passed the ISO9001 certifications early in 1997 and passed ISO9001: 2000 certifications in 2003.
Currently, we have built a full product chain of 5 series with near 30 kinds including stone crushing, sand making, ore separating, cement manufacturing, basing on the main products like crusher, ball mill, rotary kiln, and assisting by vibrating screen, vibrating feeder and dust collector, etc. The advantages of high technology, higher reliability and lower operation and maintenance cost make our products the leading industrial position. Our products have been used for the international mining and construction industries in more than 40 Countries. We own a sale and service team with rich experience and good technology and an integrated sale and service network. With our high quality products and sincere service, we are recognized and praised by our customers, the mining industry and our competitors.
Henan Dajia welcome everybody all over the world.
