Product Specifications
Product Description
Main technical index:
1.DC~20MHz,5mV~10V/div 1-2-511,±5%,×5±10%,:Y1,Y2,,,,X-Y;:1±5%MΩ//≤30pF(),10±5%MΩ//≤23pF();:400V(DC+ACp-p);
1. Bandwidth of DC to 20 MHz, vertical deflection coefficient 5mv to 10V/div by 1-2-5 carry is divided into 11 file. Error of plus or minus 5%, x 5 error of + / - 10% expansion, work: Y1, Y2, alternate, intermittent, superposition, X-Y; input impedance volume: 1 + 5%M OMEGA / / < 30pf (direct), 10 + 5%M OMEGA / / is less than or equal to 23pF (the probe); maximum input voltage of 400V DC+ACp-p;
2.::,,,;0.1μs~0.2s/div 1-2-520,±5%,×5 ±10%;
2 level system: display mode: Auto, trigger, lock, single, scan time factor 0.1 s ~ 0.2s/div by 1-2-5 carry altogether 20 file, error + 5%, expand * 5 error + 10%;
3.:Y1,Y2,,,;:AC/DC()/TV;:+,-;:50Hz~20MHz;
3 trigger source: Y1, Y2, alternating, power supply, external; coupling: AC/DC (outside) normal /TV; polarity: +, -, synchronous frequency range: automatic 50Hz ~ 20MHz
Jiangsu Sainty International Group Co. Ltd is the key enterprise, industry of our country electron instrument of national key high-tech enterprises and national Shou contract re credit enterprises. Enterprise was founded in 1970, mainly engaged in the scope of electronic measuring instruments of the R & D and production. The main products include: Oscilloscope, signal generator, the DC power supply, AC voltmeter, component parameter tester, digital bridge, environmental protection, bio engineering equipment, digital video surveillance system, toll system, railway electric appliance and so on more than 200 varieties.
