Shenzhen Noveled Technology Co., Ltd. >> Outdoor Full Color LED Display with High Resolution

Outdoor Full Color LED Display with High Resolution

Name: Outdoor Full Color LED Display with High Resolution
Brand: china-manufacturer-directory.com
SKU: 755167155
Availability: InStock
Rating: 4.6 (95 reviews)

Supplier:	Shenzhen Noveled Technology Co., Ltd.
Price:	US $ 1018/Square Meter
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB,CIF,EXW

Product Specifications

Prod Model:	P10 High Resolution LED Display
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Brightness:	More Than 7500 CD /Sqm
LED Standard:	SMD3535
Module Size:	160*160
Cabinet Material:	Iron or Aluminum
Display Type:	LED Video Display
Tube Chip Color:	Full Color
IP Rating:	IP65
Pixel Configuration:	1R, 1G, 1B
Certification:	CCC
Pixel Pitch:	10mm
Display Function:	Video Display
Application:	Advertising
Scanning Mode:	1/4 Scan
Pixel Density:	10000 dot / m²
Average Power Consumption:	220W / m²

Product Description

Outdoor P10 High Bright Full Color LED Display

1. Applications:
Our full color LED display are widely used in commercial advertising, entertainment industry, financial industry, communications, power sector, traffic, stadium, plaza, school, airport, bus station etc., for advertising and displaying messages.

2. High brightness:
We display support automatically or manually adjust the brightness of the LED display screen.

3. Good LED chip:
High strictly selected LED chips to ensure the long lifetime and high brightness of our LED display system.

4. Clear vivid image quality:
Throughout the show, the picture clear, bright color.

5. Installation is simple, easy to use:
Easy and simple installation interface and user friendly software to ensure that customers use easily.

Outdoor P10 High Bright Full Color LED Display
S/N	Item			Technical Parameters
LED Parameters
1	Item Name	LED Type			Brightness	Wave Length	H/V Visual Angle
2	Red LED	DIP346			1000-1100mcd	620-625nm	110º/50º
3	Green LED	DIP346			2000-2200mcd	520-525nm	110º/50º
4	Blue LED	DIP346			400-600mcd	470-475nm	110º/50º
Module Specifications
1	Pixel Pitch		10mm
2	Pixel Configuration		1R1G1B
3	Module Resolution		16 x 16
4	Module Pixles		256
5	Module Size		160mm X 160mm
Cabinet Specifications
1	Cabinet Size		960mm x 960mm
2	Module Quanity (pcs)		36pcs
3	Pixel Density		10000 dot/m2
4	Cabinet Materials		Iron or Aluminum
Whole Screen Specifications
1	Screen Brightness		≥6500cd/m2
2	Driving Method		1/4 scan
3	Mini Viewing Distance		10m
4	Max. Power Consumption		1000W/m2
5	Average Power Consumption		600W/m2
6	Gray Level		8bits input, 4096 levels(212)
7	Display Color		16M
8	Frame Frequency		≥60Hz
9	Refresh Frequency		≥600Hz
10	Uninterrupted Working Hours		≥72 hours
11	Screen Life-span		≥50,000 hours
12	MTBF		≥5,000 hours
13	Discrete Blind Spot Rate		<1/10000
14	Continuous Blind Spot Rate		None
15	Blind Spot Rate		<1/10000
16	Protective Scale		IP65
17	Screen Plainness		<±1mm
18	Power Supply Mode		AC220±10% 50Hz/AC110±10% 60Hz
19	Environment Temperature & Humidity		Temperature:-20 Celsius~+60 Celsius Humidity:10%~90% RH
20	Control Mode		Synchronous display with control PC by DVI
21	Control System		DVI video card + full color control card + fiber system( optional)
22	Display Content		Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.
23	Interface		Standard Ethernet
24	Transmission Distance		Multi mode fiber <500m, single mode fiber <30km,internet cable <100m

Shenzhen Noveled Technology Co., Ltd ( Noveled ) is a subsidiary of Noveled Group Co, Ltd...Noveled is a national level and high & new technology enterprise which specialize in designing, researching, manufacturing and selling all kinds of LED displays. & LED lighting...

With several years of development, NOVELED own its factory workshop area about 2, 000sqm, professional clean room, Siemens high-speed placement machine, automatic plug Universal, computer intelligence environmentally friendly lead large wave soldering, reflow (8 for 8 microcirculation heat treatment technology), Intelligent glue large stroke machine., monthly capacity is 1000sqm We are an ISO 9001: 2000 company, CE certified, export licence holders. We have the honor to work for hundereds of customers in over 400 cities of 33 provinces in China, and we also have built long-term business relationship with the customers all over the world, for example, PCS Sound in Austria, Screen world in Korea, Mega LED in Turkey, Internacionmidia in Brazil and so on.

NOVELED products widely used in outdoor advertising, cultural and recreational activity, stadium, stage background rental, With its full color LED displays advantages, from the design, productions, installation to the maintenance, Use of comprehensive integration solutions, effectively reduce the overall cost for customers, so as to create more value for customers.

We adhere to the "customer first, quality first, reputation first, " as operating principle. Our assurance is to provide our customers best products with high quality and most reasonable prices above your level of satisfaction.
