Product Specifications
| Prod Model: |
DZF-6090LC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Temperature Controller: |
Microcomputer Temperature Control |
| Work Chamber Material: |
Stainless Steel |
| Door: |
Is Made of Bulletproof Glasses |
| Silicon Door Seal: |
Is of Good Seal Performance |
| Vacuum Display: |
Digital Display |
| Operational Method: |
Continuous |
| Operation Pressure: |
Vacuum Dryer |
| Drying Medium: |
Vacuum |
Product Description
Application range:
This type of product is suitable for research institute, hospitals and mining industries. It specializes in the drying heating -sensitive, easily oxidized and easily decomposed substances, and can quickly dry products made of complex substances, and can fill in the workroom with noble gas.
Structural characteristics:
It adopts microcomputer intelligent temperature controller which is accurate and reliable.
The heaters control the temperature separately, which is installed on the shelf in the box. He heating time is shortened, and the uniformity is good.
The workroom is made of stainless steel plate and is polished, which is aesthetics and durable.
The door is made of double bullet-proof and tempered glasses, to ensure the safety of the operator.
The door seal is made of silicon rubber seal, and the tightness can be adjusted, which ensures the vacuum in the workroom. And can fill the noble gas into the workroom. (when infill the gas, please pay attention that the gas pressure shouldn't be larger than 0.1MPa)
It adopts digital display of microcomputer process control to display the vacuum. The maximum times of process cycle is up to 99.
|
Model |
DZF-6090LC |
DZF-6210LC |
|
Item |
|
Power source |
AC220V 50Hz |
|
Rated power |
1.6Kw+/-10% |
2.2Kw+/-10% |
|
Temperature control range |
50~200°C |
|
Temperature fluctuation |
+/-1°C |
|
Vacuum degree |
<133pa |
|
Work room dimension(cm) |
45X45X45 |
56X60X64 |
|
Outline dimension(cm) |
61X66X145 |
72X82X175 |
|
Package dimension(cm) |
78x76x163 |
89x92x193 |
|
Net/gross weight(kg) |
145/195 |
|
Note: |
Vacuum programme control |
