Overflow Type Ball Mill

Name: Overflow Type Ball Mill
Brand: china-manufacturer-directory.com
SKU: 676633432
Availability: InStock
Rating: 4.8 (77 reviews)

Supplier:	Zhengzhou Vipeak Heavy Industry Machinery Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CIF

Product Specifications

Prod Model:	MQY
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Mineral Processing & Screening Equipment
After-Sale Service:	Installation and Permanent Maintain
Supporting Facilities:	Design Whole Production Line
Color:	Any Color Is Available
Capacity/Set:	0.5-97 Tons/Hour
Output Size:	Adjustable
Input Size:	<35mm
Mining Object:	Coal Machinery
Certification:	CE, ISO9001, Iqnet, Gost
Application:	Construction, Mining, Chemical, Beneficiation

Product Description

Overflow Type Ball Mill is Applicable for grinding various ores and other materials; It is widely used in mineral processing, building materials, chemical industry and ect. It can be divided into dry and wet grinding way. According to the ways of discharge, it can be divided into grate ball mill and overflow ball mill.

Characteristics of superfine ball mill:

Different design from traditional cement and mining processing, and in line with the requirements of Germany superfine material feeding and processing.
Optimize length-diameter ratio to avoid over-grinding and achieve the best effect of grinding.
Optimize aperture ratio and design of grate board, and improve the fineness by using lesser grinding medium.
Discharge the powder by grid smoothly, no need cooling for the cylindrical shell.
Optimize liner and the shape and the material for grinding medium, reduce the damage rate and improve the grinding efficiency according to Germany requirements.
For hard minerals, adopt Non-iron pollution design. Use alumina ceramics, quartz, silex and other special material for liner and grinding medium.
Adopt reasonable grinding medium as required, high feeding ratio and high efficiency.
Add grinding additives when grinding ultra-fine powder to improve grinding efficiency.
Optimize the matching of the energy consumption and grinding drive, reduce energy consumption.
Formed a closed system with classifier, negative pressure conveying and less dust.

Model	Cylinder diameter (mm)	Tube length(mm)	Effective Volume (m3)	Mill rotation speedr/min	Grinding media loading(t)	Transmission model	Main motor		Reference weight(t)	Remarks
Model	Cylinder diameter (mm)	Tube length(mm)	Effective Volume (m3)	Mill rotation speedr/min	Grinding media loading(t)	Transmission model	Power (kw)	Speed (r/min)	Reference weight(t)	Remarks
MQY15× 30	1500	3000	5	26.6	9	fringe	95	742	18.5	drum feeder
MQY15× 36	1500	3600	5.7	26.6	10.6	fringe	95	742	17.22	Rubber liner
MQY21× 30	2100	3000	9.4	22.1	15	fringe	200	740	45
MQY24× 30	2400	3000	12.2	21	22.5	fringe	250	980	55
MQY27× 36	2700	3600	18.5	20.5	39	fringe	400	187.5	61.34
MQY27× 45	2700	4500	23.5	20.5	43.5	fringe	500	187.5	76
MQY28× 80	2800	8000	43	20	78.6	fringe	800	137	115	coal water slurry
MQY32× 36	3200	3600	26.3	18.3	48.4	fringe	500	167	116.94
MQY32× 45	3200	4500	32.9	18.3	60.5	fringe	630	167	124.23
MQY32× 75	3200	7500	55.5	18.3	102	fringe	1250	734	154
MQY34× 45	3400	4500	37	18.4	74.6	fringe	800	167	129.8
MQY34× 56	3400	5600	45.8	17.9	84.3	fringe	1120	985
MQY36× 50	3600	5000	46.7	17.5	85.96	fringe	1250	167	150
MQY36× 60	3600	6000	54	17.3	102	fringe	1250	167	162.7
MQY36× 90	3600	9000	83.5	17.4	138	centre	1800	743	286
MQY40× 60	4000	6000	69.8	16	126	fringe	1500	200	203.5
MQY40× 135	4000	13500	155	16	233	fringe	3300	200	343	coal water slurry
MQY43× 61	4270	6100	80	15.67	144	fringe	1750	200	215.3
MQY50× 64	5030	6408	120	14.4	251	fringe	2600	200	318.5
MQY55× 65	5500	6500	143.3	13.8	264	fringe	3400	200	451.5
