Product Specifications
| Prod Model: |
Kingkar7000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Kingkar-7000 |
| Input Power: |
3 Phase 380V (50-60)Hz±10% |
| Rated Capacity (kVA): |
22 |
| Working Current (a): |
350 |
| Work Pressure (Mpa): |
≤0.2 |
| Rated Gas Production (L/H): |
7000±10% |
| Water Consumption (L/H): |
3.8 |
| Effective Perforation Thickness (Mm): |
90 |
| Cooling Way: |
Air Cooling |
| Appearance Size (L*W*H)Mm: |
1250*850*1830 |
| Type: |
Flame |
| Control Mode: |
CNC |
| Cutting Mode: |
Flame |
Product Description
Cutting methods on the market today generally use oxygen and acetylene, propane, coke oven gas and other gases. Through experiment and practice, the use of hydrogen energy and water consumption reduce the cost of forty percent lower than traditional methods to 60 percent.
Hydrogen gas is separated from the water electrolysis hydrogen and oxygen gas for industrial cutting.
Hydrogen machine has a ten-year lifetime. Calculated according to a decade, the use of hydrogen energy machine at least 3-5 times the cost savings, which is increased by 3-5 times for the use of units and profits in various fields.
Working Principle
1. The principle is based on the theory of electrolysis.
2. It is consumed only water and electricity in the course of using
3. To electrolyze water into pure hydrogen and oxygen.
4. Burning the gas then form Oxy-hydrogen flame.
5. Oxy-hydrogen flame is a high temperature energy source which can be used for precision cutting processing equipment, giving results that are economical, reliable, safe and environmental.
Product features
1. It is a mature production technology, which can be operated
Safely and reliably.
2. The process flow is short and simple.
3. Both energy consumption and production cost are relative low.
4. Simple and easy operation, high automation.
5. No environmental pollution.
Functions and Characteristics of the Products:
Electrolysis of pure water to produce hydrogen with no corrosion and pollution, and the purity of hydrogen is extremely high.
With stable pressure and output, Hydrogen is controlled according to the requirements, and automatic control technology is perfect and reliable.
Power consumption is less, and the electrolysis is efficient.
Application field
Suitable for all the needs of the flame processing establishments, used to replace acetylene, propane, liquefied petroleum gas and other gas, commonly used in steel cutting, welding metal oxide, jewelry processing require high energy gas plant, glass processing.
We can do OEM and also can design as your special request.
Welcome to visit our factory at any time in the future.
| Model | Kingkar-3000 | Kingkar-5000 | Kingkar-7000 | Kingkar-10000 |
| Voltage(V) | 380 ±10%,50/60Hz,three phase |
| Rated capacity(KVA) | 9 | 15 | 22 | 31 |
| Working pressure(Mpa) | ≤0.2 |
| Relative humidity(%) | ≤90 |
| Rated gas output(L/H) | 3000±10% | 5000±10% | 7000±10% | 10000±10% |
| Water consumption(L/H) | 1.6 | 2.7 | 3.8 | 5.8 |
| Maximum Cutting Thickness(mm) | 110 | 220 | 310 | 420 |
| Effective perforated thickness(mm) | 40 | 60 | 70 | 90 |
| Cooling way | Air cooling |
| Insulation class | F |
| power protection grade | IP2S |
| Flame temperature(T) | 800-3200 adjustable |
| Working medium | Filtered water or deionized water or soft water |
| Working | continuous |
| environment temperature(T) | 0-40 |
| Dimension(L×W×H)mm | 1020*770*1270 | 1250*830*1720 | 1300*930*1820 | 1500*930*1940 |
| Weight(KG) | 293 | 567 | 653 | 894 |
KingKar provides green energy solutions. We are specialized in Oxy-Hydrogen Generator, which changes soft water into a clean burning fuel that can be used to replace traditional gas fuels. We offer this safe, clean and pollution-free new source of green energy for mankind. Our development concept is based on creating a cleaner living environment around the world and promoting the use of sustainable energy sources.
KingKar Oxy-hydrogen generator for boiler only consumes water
And electricity to create oxy-hydrogen gas which feeds into to the combustion chamber for complete burning. It increases the combustion efficiency of the existing fuel etc. There is no pollution, no harmful gases or other chemical additives.
Our machine content: Oxy-hydrogen generator for boiler, Oxy-hydrogen used in industrial furnace, Oxy-hydrogen used in medical care, industrial And household wastes incinerator, Oxy-hydrogen used in generator, Oxy-hydrogen used in clean coal combustion technology, Oxy-hydrogen used in pharmaceutical industry and etc
