| Supplier: | Shenzhen LEDSolution Technology Co., Ltd. |
|---|---|
| Price: | Negotiable/Square Meter |
| Min Order: | 1/Piece |
| Quantity:: | |
| Trade Terms: | FOB |
|
|
| Prod Model: | LS-I-P10 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brightness: | 1,500nits |
| Panel Weight: | 48kg |
| Panel Material: | Epoxy Paint Coated Cold Rolled Steel |
| Recommended Minimum Viewing Distance: | 7.6m |
| Recommended Best Viewing Distance: | 13~34m |
| Multimedia Data Format: | DVI, Mpg, AVI, WMV, RM etc. |
| Data Interconnection: | UTP Cat 5/Optical Fiber |
| Mounting System: | Fixed with 4PCS M10 Bolts |
| Tube Chip Color: | Full Color |
| Display Function: | Video Display |
| Pixel Pitch: | 10mm |
| Pixel Density: | 10,000 dots / m² |
| Scanning Mode: | 1/4 Scan |
| Display Type: | LED Video Display |
| Application: | Advertising |
| IP Rating: | IP43 |
| Certification: | ETL |
| Pixel Configuration: | 3in1 SMD |
| Parameter | Unit | Value |
| Pitch | mm | 10 |
| Brightness | nits | 1, 500 |
| Color temperature | deg. K | 6, 500 |
| Viewing angle - Horizontal (50% brightness) | deg. | 140(-70 ~ +70) |
| Viewing angle - Vertical (50% brightness) | deg. | 140(-70 ~ +70) |
| Panel weight | kg | 48 |
| Panel width | mm | 960 |
| Panel height | mm | 960 |
| Panel depth | mm | 150 |
| Panel area | sq. m. | 0.9216 |
| Panel material | Epoxy paint coated Cold rolled steel | |
| Operating temperature range | deg. C | -30 to +60 |
| Humidity operating | RH | 10% ~ 90% |
| Pixel type and configuration | R/G/B | 3in1 SMD |
| Resolution per panel | 96x96 | |
| Dot per panel | 9, 216 | |
| Dot per sq. meter | 10, 000 | |
| LED per sq. meter | 10, 000 | |
| Recommended minimum viewing distance | m | 7.6 |
| Recommended best viewing distance | m | 13~34 |
| Colors | 1, 073.7 million | |
| Grey scale (linear) | Levels | 1, 024 levels per color |
| Brightness control | Levels | 100 |
| Contrast ratio | 1, 000: 1 | |
| Processing depth | bit | 16 |
| Video frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 180~3, 000 |
| Input voltage (nominal) | VAC | 110 to 240 |
| Input power frequency | Hertz | 50 to 60 |
| Input power (max) | Watts /sq. m. | 488 |
| Input power (typical) | Watts /sq. m. | 195.2 |
| Lifetime (50% brightness) | Hours | ≥ 100, 000 |
| Red wavelength (dominant) | nm | 620~625 |
| Green wavelength (dominant) | nm | 525~530 |
| Blue wavelength (dominant) | nm | 470~475 |
| Multimedia data format | DVI, MPG, AVI, WMV, RM etc. | |
| Data interconnection | UTP Cat 5/Optical Fiber | |
| Mounting system | Fixed with 4pcs M10 bolts |
