P10 Indoor Full Color SMD LED Display

Name: P10 Indoor Full Color SMD LED Display
Brand: China-Manufacturer-Directory.com
SKU: 774144645
Availability: InStock
Rating: 4.5 (131 reviews)

Supplier:	Shenzhen Foxgolden Technology Limited
Price:	US $ 385-462/Square Meter
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	FOX-p10 indoor
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size Of Unit Board:	160mm*320mm
Resolution Of Unit Board:	16*32
Density Of Pixel:	62500dots/Sqm
Pixel Configuration:	SMD 3 in 1
Consumption:	500-1000W/Sqm
Brightness:	1400-9500CD/Sqm
Driving Method:	1/8 or 1/4scaning
Tube Chip Color:	Full Color
Display Function:	Video Display
Pixel Pitch:	10mm
Pixel Density:	10,000 dots / m²
Scanning Mode:	1/8 Scan
System Operating Platform:	WIN XP
Display Type:	LED Video Display
Application:	Shopping Guide
IP Rating:	IP43
Pixel Configuration:	SMD 3 in 1

Product Description

Feature and Advantage
1. Waterproof: IP54front, IP45back
2. Best viewing distance: 8-150m
3. White balance brightness: 3000CD/sqm adjustable
4. Horizontal viewing angle: 120degree
5. Working temperatue: -20degree-+80degree
6. Life span: More than 100, 000hours
7. Contrast ratio: 4000: 1
8. Pconsumption: 200W

Application and Market
1. Application
Wide applied in stadiums, advertisement, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
2. Market:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe

Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM, any your customized lightings we can help you to design and put into product
3. Distributoership are offered for your unique design and our current models
4. Protection of your sales area, ideas of design and all your private information

Trade Terms
1. Package: Wooden package, Air flight case or Carton package
2. Payment: T/T, 40% deposits, 60% balance before delivery 3. Shipping port: Shenzhen
4. Warranty time: 7years
5. Delivery time:
Sample order, 3working days;
10sqm-50sqm, 8-18working days;
50sqm-100sqm, 25-28working days;

Description	Technical parameter
Unit module	Module size	160*320mm
	Pixel pitch	10mm
	Pixel density	10, 000dots/m2
	Pixel configuration	3 in 1
	Led specification	SMD3528
	Pixel resolution	W: 16dots*H: 16dots
Cabinet	Dimension	960mm960mm110mm
	Cabinet material	Aluminum
	Weight	45 kg/sqm
	Quantities of module	36pcs
	Power supply	6pcs
	Thermal discharge	Fan*2pcs
	Total weight	65kg
	Best viewing angle	10-100m
	Temperature	Storage: -35degree~+85degree
	Temperature	Working: -35degree~+85degree
	Thickness	11cm can adjustable
	Remarks: cabinet size can changed, upon project need.
Power	Working voltage	AC220V/110V± 10%
	Average power consumption	200W
	Max. Power consumption	≤ 1000W/sqm
	Current	≤ 20mA(single LED)
Control system	CPU	Pentium4 or above
	Operating system	WIN98/2000/NT/XP
	Control method	Synchronization
Main technical parameter	Driving device	1/4scanning
	Drive type	Constant Current driver IC
	Refresh frequency	≥ 400Hz
	Grey scale/colors	256 levels of each color(R/G/B)/16.7M color
	Brightness of white balance	1500-2800cd/sqm can adjustable
	Brightness adjustment	256 levels of each color(R/G/B)by software
	Operating ambient humidity	10%--95%
	Video signal	PAL/NTSC
	Control system	DVI display card+full color controller card
	MTBF	≥ 10, 000hours
	Life span	≥ 100, 000hours
	Flatness	Tolerance of interpixel ≤ 0.3mm
	Flatness	Tolerance of modules clearance≤ 0.6mm
	Power switch	Automatic switch
	Display mode	1024*768
	Communication distance	Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m. Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KM
Software	LED media player

Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.

As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.

Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.

Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.

With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
