Product Specifications
| Prod Model: |
P16 outdoor full color |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Display Type: |
LED Video Display |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Application: |
Advertising |
| Pixel Configuration: |
1R, 1G, 1B |
| Pixel Pitch: |
12mm |
| Display Function: |
Video Display |
| Scanning Mode: |
Static Scan |
| Certification: |
ETL |
| Average Power Consumption: |
350W / m² |
| Pixel Density: |
3906DOT |
Product Description
Product Description
Competitive Advantage:
1. Wide application field & short ROI time: Commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instruction
2. High Contrast: 4000: 1, which is a very high level to ensure a vivid image of our LED display screen system...
3. First-class LED chip: Supplied by COTCO/CREE/AXT/SILAN/TAI WAN LED lamps to ensure the long lift-time and high brightness of our LED display screen system
4. Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROI of your LED display screen's investment.
5. Long-term Brightness: 9000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.
6. Easy Installation & Using: Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
7. Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized lightings we can help you to design and put into product
3. Distributoership are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top Quality+Reasonable Price+Responsible After Service=Successful & Win
|
Numbers |
Technical indexes |
Specification |
|
1 |
Pixel Pitch |
16mm |
|
2 |
Density of Pixel |
3906dots/M2 |
|
3 |
Pixel configuration |
RGB |
|
4 |
Size of Single Board |
384mm X 192mm |
|
5 |
Colors |
16777216 |
|
6 |
Best Viewing Distance |
≥6m |
|
7 |
Horizontal Viewing Angle |
140° |
|
8 |
Maximum Power Consumption |
300W/m2 |
|
9 |
Brightness |
1800nits/m2 |
|
10 |
Gray Scale |
15 bits per color |
|
11 |
Color Temperature |
8500cd/m2 |
|
12 |
Control Method |
synchronization &
Asynchronization |
|
13 |
Driving method |
constant scanning |
|
14 |
Frame Frequency |
60Hz |
|
15 |
Refresh frequency |
≥480Hz |
|
16 |
Working Voltage |
AC220V/110±10% |
|
17 |
IP grade |
IP67 |
|
18 |
Working temperature |
10 degree centigrade ∼ +80 degree centigrade |
|
19 |
Computer operation system |
Win 98/ Win XP/ Win 2000/winme/win7 |
|
20 |
Brightness adjustment |
256 grade manual, 8 grade automatic |
|
21 |
Video signal |
RF, S-Video, RGB, RGBHV, YUV, YC.ect |
|
22 |
Software |
LED play software |
|
23 |
MTBF |
More than 10000 hours |
|
24 |
Life Span |
100,000 hours |
