Supplier: | Shenzhen Teeho Optoelectronic Co., Ltd. |
---|---|
Price: | US $ 800-1500/Square Meter |
Min Order: | 1/Square Meter |
Quantity:: | |
Trade Terms: | FOB,CIF,EXW |
![]() |
Prod Model: | p3 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Pixel Configuration: | SMD 2121b |
Module Size: | 192*192 |
Driving IC: | Mbi5124 |
Brightness: | 1200CD/M2 |
Contrast: | 1000:1 |
Frame Frequency: | 65Hz |
Refresh Rate: | >3200Hz |
Grey Processing: | 14 Bit |
Display Type: | LED Video Display |
Tube Chip Color: | Full Color |
Display Function: | Video Display |
Scanning Mode: | 1/16 Scan |
Certification: | CCC |
Pixel Configuration: | 1R,1G,1B |
Application: | Advertising |
IP Rating: | IP43 |
System Operating Platform: | WIN XP |
Pixel Pitch: | 3mm |
Pixel Density: | 111111 |
Specitication: | P3 LED Panel Specification | |||||||||||
NO: | Product Name | Specification | ||||||||||
1 | Pixel Pitch | 3mm | ||||||||||
2 | Pixel Configuration | 1R1G1B/SMD2121 Black lamp | ||||||||||
3 | Density | 111,111 pixel/m2 | ||||||||||
4 | Moduel Size(L×W)mm | 192mm×192mm | ||||||||||
5 | Cabinet Size(L×W×H)mm | 576mm×576mm×70mm | ||||||||||
6 | Module Resolution | 64×32 | ||||||||||
7 | Cabinet Resolution | 192×192 | ||||||||||
8 | Driving Method | 1/16 Scan | ||||||||||
9 | Driving IC | MBI5024 | ||||||||||
10 | Brightness | 1200cd/ | ||||||||||
11 | Contrast | 1000:01:00 | ||||||||||
12 | Brightness Adjustment | AC 85-264V | ||||||||||
13 | Power Consumption | Max Power:<2100W | ||||||||||
14 | Average power: <1260W | |||||||||||
15 | Cabinet Weight | <14kg | ||||||||||
16 | Color Temperature | 3200K-9300K | ||||||||||
17 | Horizontal Viewing Angle | 120º | ||||||||||
18 | Vertical Viewing Angle | 90º | ||||||||||
19 | Signal Processing | 10 or 14bit | ||||||||||
20 | Grey Processing | 1024×1024×1024 16834×16834×16834 | ||||||||||
21 | Control Distance | Cable100m,Multimode500m,Single mode 2km | ||||||||||
22 | Frame Frequency | 60 Hz | ||||||||||
23 | Refresh Rate | >600Hz | ||||||||||
24 | Control Mode | Synchronous/Asynchronous | ||||||||||
25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
26 | Users can choose the recommended curve, also can be adjusted according to actual situation | |||||||||||
27 | MTBF | ≥50000 hours | ||||||||||
28 | Life Span | 100,000 Hours | ||||||||||
29 | Operating Temperature | Working : 35 - 90ºC | ||||||||||
30 | Storage : 10 - 99ºC | |||||||||||
31 | Environment Temperature | -30ºC to 60ºC; humidity Rh10% to 95% | ||||||||||
32 | Remote Control | Can realize remote control,For the possibility of potential failure logging, and send alarm signal to the operator (need to customize) | ||||||||||
33 | Self-checking Technique | LED a single point of self-inspection, communications test, power test, temperature monitoring (need to customize) | ||||||||||
34 | System Operating Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
35 | Power Supply | AC 85-264V | ||||||||||
36 | Protection | waterproof, dustproof, high temperatureproof,anti-corrosion, anti-burning,anti-static,shake proof,thuner-proof,the system with smoke alarm and temperature alarm function. (need to customize) |
