Supplier: | Shenzhen LEDSolution Technology Co., Ltd. |
---|---|
Price: | Negotiable/Piece |
Min Order: | 1/Square Meter |
Quantity:: | |
Trade Terms: | FOB |
![]() |
Prod Model: | LS-O-P5.33-SMD-0.64mx0.64m |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Brightness: | 6, 000nits |
Color Temperature: | 6, 500deg. K |
Panel Size: | 640X640mm |
Resolution Per Panel: | 120X120 |
Panel Weight: | 15kg |
Panel Material: | Epoxy Paint Coated Cold Rolled Steel |
Tube Chip Color: | Full Color |
IP Rating: | IP65 |
Display Function: | Video Display |
Display Type: | LED Video Display |
Application: | Advertising |
Certification: | ETL |
Pixel Pitch: | 5.33 |
Pixel Configuration: | 3in1 SMD |
Average Power Consumption: | 240W/M&Sup2 |
Pixel Density: | 34,969 DOT/M&Sup2 |
Parameter | Unit | Value |
Pitch | mm | 5.33 |
Brightness | nits | 6,000 |
Color temperature | deg. K | 6,500 |
Viewing angle - Horizontal (50% brightness) | deg. | 140(-70 ~ +70) |
Viewing angle - Vertical (50% brightness) | deg. | 140(-70 ~ +70) |
Panel weight | kg | 15 |
Panel width | mm | 640 |
Panel height | mm | 640 |
Panel depth | mm | 150 |
Panel area | sq. m. | 0.4096 |
Panel material | Epoxy paint coated Cold rolled steel | |
Ingress protection (front/rear) | IP | IP65/IP43 |
Operating temperature range | deg. C | -30 to +60 |
Humidity operating | RH | 10% ~ 90% |
Pixel type and configuration | R/G/B | Outdoor 3in1 SMD |
Resolution per panel | 120x120 | |
Dot per panel | 14,400 | |
Dot per sq. meter | 34,969 | |
LED per sq. meter | 34,969 | |
Recommended minimum viewing distance | m | 4 |
Recommended best viewing distance | m | 5~20 |
Colors | 281 Trillion | |
Grey scale (linear) | Levels | 65,536 levels per color |
Brightness control | Levels | 100 |
Contrast ratio | 1,000:1 | |
Processing depth | bit | 16 |
Video frame rate | Hertz | 60 |
Display refresh rate | Hertz | 180~3,000 |
Input voltage (nominal) | VAC | 110 to 240 |
Input power frequency | Hertz | 50 to 60 |
Input power (max) | Watts / panel | 600 |
Input power (typical) | Watts / panel | 240 |
Lifetime (50% brightness) | Hours | ≥100,000 |
Red wavelength (dominant) | nm | 620~625 |
Green wavelength (dominant) | nm | 525~530 |
Blue wavelength (dominant) | nm | 470~475 |
Multimedia data format | DVI,MPG,AVI,WMV,RM etc. | |
Data interconnection | UTP Cat 5/Optical Fiber | |
Mounting system | Fixed with 4pcs M10 bolts | |
Controller | Linsn/NOVA/DBStar |
