P5 Full Color Indoor LED Display for Show

Name: P5 Full Color Indoor LED Display for Show
Brand: China-Manufacturer-Directory.com
SKU: 755686055
Availability: InStock
Rating: 4.7 (71 reviews)

Supplier:	Shenzhen Noveled Technology Co., Ltd.
Price:	US $ 1165/Square Meter
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB,CIF,EXW

Product Specifications

Prod Model:	P5 Full Color Indoor LED Display for Show
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size:	320*160
Cabinet Size:	640*640
Warranty:	Two Years
Display Type:	LED Video Display
Tube Chip Color:	Full Color
Display Function:	Video Display
Scanning Mode:	1/16 Scan
Certification:	CCC
Pixel Configuration:	1R,1G,1B
Pixel Pitch:	5mm
Pixel Density:	40,000 dots / m²
Application:	Shopping Guide
IP Rating:	IP43
System Operating Platform:	WIN XP

Product Description

P5 Indoor Full Color LED Screen
1.large viewing angle
2.High brightness
3.Light weight
4.Convenient to install and dismantle
5.Famous IC brand ensure the quality
6.Long life span

Export Markets:South America,North America,Oceania,Mid East,Africa,Western Europe,Southeast Asia
Our products cover indoor and outdoor full color LED screen, cabinet module, panel etc;

P5 Full Color SMD3528 Indoor Module
Item	Unit	Parameter
Pixel Pitch	mm	5.00
Resolution of Module	dots	32x16
Module Size	mm	160x80
Module Weight	kg	0.25
Pixel Configuration	SMD3528 1R1G1B
Chip Brand of LEDs	Epistar
Pixel Density	dots/sqm	40,000
Brightness (White Balance)	nits(cd/sq.m)	≥2000
Red Wavelength	nm	620-625
Green Wavelength	nm	520-525
Blue Wavelength	nm	470-475
Scan Mode	1/16 Scan
Viewing Distance	M	3--35
Best View Distance	M	5--15
Viewing Angle-Horizontal	deg.	120
Viewing Angle-Vertical	deg.	120
Module Maximum Power	W	25
Max. Power Consumption	W/sq.m	1,000
Avg. Power Consumption	W/sq.m	300
Working Voltage	5V 40A
Power Supply	AC 110/220V
Refresh Rate	Hz/S	3,000
Frame Rate	Hz/S	≥60
Gray Scale	4096 grades gray
Display Function	Text,news,advertising,flash,animation
Input Signal	RF,S-Video,RGB,RGBHV,YUV,YC,SDI,HD-SDI,DVI,UXGA,COMPOSITION,etc.
Luminance Degradation	Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25 centigrade.
Defective Dot Rate	<0.0001
Life Span	hours	100,000
MTBF	hours	>5,000
Storage Temperature	centigrade	-35 -- +80
Working Temperature	centigrade	-20 -- +60
Control System	Synchronization or Asynchronization
Quality Certificate	CE,CCC,ISO9001,ROHS
Warrenty	2 Years
Working Environment	Indoor

Rental LED Display Function:
1.Video Broadcast Functions
2.Information dissemination functions
3.Network functions

Good after-sale-service for customers:
1. Noveled Group provide pre-sale service in technical consultation such as recommend and design solutions for the customers'

requiements,which can help increase the risk of customers' investing;
2. We accept customers supervision during production;
3. We also provide necessary training to customers;
4. We will take great responsibility to collect customers' feedback,inspection and maintain products periodically to ensure solving problems timely.

Shenzhen Noveled Technology Co., Ltd ( Noveled ) is a subsidiary of Noveled Group Co, Ltd...Noveled is a national level and high & new technology enterprise which specialize in designing, researching, manufacturing and selling all kinds of LED displays. & LED lighting...

With several years of development, NOVELED own its factory workshop area about 2, 000sqm, professional clean room, Siemens high-speed placement machine, automatic plug Universal, computer intelligence environmentally friendly lead large wave soldering, reflow (8 for 8 microcirculation heat treatment technology), Intelligent glue large stroke machine., monthly capacity is 1000sqm We are an ISO 9001: 2000 company, CE certified, export licence holders. We have the honor to work for hundereds of customers in over 400 cities of 33 provinces in China, and we also have built long-term business relationship with the customers all over the world, for example, PCS Sound in Austria, Screen world in Korea, Mega LED in Turkey, Internacionmidia in Brazil and so on.

NOVELED products widely used in outdoor advertising, cultural and recreational activity, stadium, stage background rental, With its full color LED displays advantages, from the design, productions, installation to the maintenance, Use of comprehensive integration solutions, effectively reduce the overall cost for customers, so as to create more value for customers.

We adhere to the "customer first, quality first, reputation first, " as operating principle. Our assurance is to provide our customers best products with high quality and most reasonable prices above your level of satisfaction.
