P7.62 Indoor Full Color LED Display Screen Board

Name: P7.62 Indoor Full Color LED Display Screen Board
Brand: china-manufacturer-directory.com
SKU: 742539375
Availability: InStock
Rating: 4.4 (123 reviews)

Supplier:	CLC Display Technology Co., Limited
Price:	US $ 1-700/Square Meter
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	HX-P7.62-118
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size:	244mm X 122mm
Package Mode:	17222dots /Sqm
Gross Weight:	0.45kg
Module Thickness:	17.06mm/28.92mm
Driver Type:	Constant Type
Brightness:	≥1500CD/Sqm
Warranty:	24months(2 Years)
Display Type:	LED Video Display
Tube Chip Color:	Full Color
Display Function:	Video Display
Scanning Mode:	1/8 Scan
Certification:	CCC
Pixel Configuration:	1R,1G,1B
Pixel Pitch:	7.62mm
Pixel Density:	17,222 dots / m²
Application:	Advertising
IP Rating:	IP43
System Operating Platform:	WIN XP

Product Description

Features of our products:

Warranty:
1. We guarantee all our display, modules, spare parts (Silan Chip) for TWO years.
2. We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3. After warranty, we also can offer you the parts for replacement at our bottom price.
4. After sales, if you have any problem about our product, you can inform us by Email, we will reply you at once when we get it and offer you a good solution to solve the problem.
5. We also could solve problems for you until it recovers well by remote control!

Delivery Time:
1. Delivery time: Accomplish manufacturing within 25 days after receiving the deposit.
2. Before delivery, we will test the display, and keep it light up for 72 hours, and check all the parts of the display to confirm it is OK for delivery.

Trade Terms:
1)Payment: T/T, 30% deposits before production, 70% balance to be paid before delivery
2)Shipping freight are quoted under your requests
3)Shipping port: ShenZhen, Mainland China
4)MOQ: 1pcs

1.1 LED Index
Match colors analysis		R:G:B=3:6:1
1.2 Technology Specifications
Name	Technology Specifications
1.Physical index	Pixel :7. 62mm
	Color : Red+Green+Blue
	Pixel configuration : 1R1G1B
	Pixel density :17222 dots/sqm
	LED type : SMD3528
2 Module	Panel pixel(dots) : 32dots×16dots
	Modul size : 244mm×122mm
3 Screen	Viewing : H120 0 , V120 0
	Storage temperature : -40 °C ~~ +65 °C
	Operated temperature : -40 °C ~~+60 °C
	Humidity : 10%-95%
	Screen thickness : cabinet thickness 12cm ( Front Maintenance )
	Cabinet weight : 35kg/sqm
	Protection : IP31
4 Power supply	Power : AC220V or 380V
	Max power consumption : 1200W/sqm average 500W/sqm
5 Control system	Computer : DELL V230 or similar computer
	Operating system : WIN7/2000/XP
	Display card : DVI
	Control mode : synchronization control
	Refresh frequency : ≥ 2000Hz
	Grey/Color : 16K , 4K(Optional ) /16.7M colors
	Calibrate Brightness : 256level adjust
	Control system adopts : DVI+Master card+ Internet line
6 Main specifications	Driver : Constant current
	Driver mode : 1/8 scan
	Frame frequency : ≥ 60Hz
	Brightness :≥ 2000cd/sqm
	Accepting signal : RF , S-Video , RGB , RGBHV , YUV , YC , COMPOSITION etc
	MTBF : ≥ 1000hours ; Life-span : 100,000hours
	Level up degree : pixel ≤ 0.5mm ; module < 1mm
	Uniformity : pixel and module uniformity brightness
	Malfunction dot rate :< 0.0001
	Switch power load : 5V/40A
	Computer display mode : 1280x1024
	Control distance : internet line : 100m ; single mode fiber: 20km ; multi mode fiber:500m

Shenzhen Huaxia L&C Display Technology Co., Ltd(CLC display company), a LED display company located in Baoan district, Shenzhen. Based on our 3 factories(total 15200 square meters), we designs and develops visualization solutions for a variety of products selected from professional markets: Advertisement, Media, Sports, Entertainment, digital cinema, CCTV security, simulation & virtual reality. In these markets, Huaxia offers user-friendly imaging products that optimize productivity and business efficiency.

Integrating visualization technology requires specialist know-how and expertise and that's exactly what we can offer you - before, during and after the sale. We offers a complete range of high-impact video display systems, image processing and content management technology for permanent installations, rental and staging markets. Based on our staff with a couples of experience, We provide the right visualization technology to match your needs.

As a OEM/ODM factory, we are supplying both LED display and LED module to the overseas and domestic buyers. We supports our customers to finish more than 1, 500 events every year, which are from more than 60 countries and regions.

Main product list:

Indoor display, outdoor display, outdoor/indoor display mesh

Pixel pitch:

From P1.5, P1.875, P3.0, ...P31.25

Application locations:

Outdoor, Indoor and semi-outdoor

Application markets:

Advertisement, Media, Sports, Entertainment, Digital cinema, CCTV security, Simulation & virtual reality
