P7.62 Indoor Full Color LED Display (UVO-P7.62-FLI)

Name: P7.62 Indoor Full Color LED Display (UVO-P7.62-FLI)
Brand: china-manufacturer-directory.com
SKU: 675296765
Availability: InStock
Rating: 4.8 (109 reviews)

Supplier:	Universe Optoelectronics Co., Ltd.
Price:	US $ 700/Square Meter
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB,CIF,EXW

Product Specifications

Prod Model:	UVO-P7.62-FLI
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
LED Type:	SMD3528
Module Size:	244X122mm
Display Type:	LED Video Display
Tube Chip Color:	Full Color
Display Function:	Video Display
Scanning Mode:	1/8 Scan
Application:	Stage Performance
Pixel Configuration:	1R,1G,1B
Pixel Pitch:	7.62mm
IP Rating:	IP54
Certification:	RoHS
Pixel Density:	17,222 dots / m²
System Operating Platform:	Windows2008

Product Description

1) Widely used in shopping centre, airport, train station and etc.
2) Environment-protection and energy-saving.
3) Advanced digital technology for video.
4) Be able to show video, cartoon, graphics, text, pictures and etc.
5) Indoor LED display
6) High brightness
7) Light weight and ultra thin
8) Good stability
9) Advertising indoor LED Display Screen Professional Manufacturer

Pixel Pitch	7.62mm
Pixel Density(dot/m² )	17222
Pixel Configuration	1R1G1B
Packaged Type of LED	SMD
Module Size(mm)	244X122
Module Resolution	32X16
Brightness(cd/m² )	3500
Max Power Consumption(w/m² )	700
Best Viewing Distance(m)	7-21
Viewing Angle	120° V/120° H
Drive Mode	Constant Current drive 1/8 scan
Driving	Driving IC MBI5026GF
Frame-change Frequency	≥ 60 Hz/s
Refresh Rate	≥ 400Hz/s
Gray Grade Level	4096 grades
Display Mode	1024*768
Control System	Synchronization Control
Transmission Distance	Reticle ≤ 100M; Multi-mode Fiber ≤ 500M Single-mode Fiber ≤ 10000M
Out of Control	Rate ≤ 0.0001
Lifespan	≥ 100000H
Driving Power	5V
Working Voltage	AC220V± 10% 47HZ ~ 60hz
Working Temperature	-10 ° C~ +55 ° C
Working Humidity	5%RH ~ 85%RH

Universe Optoelectronics Co., Ltd. is a high-tech private company who combines research, development, production and Sales into one kit. It is one of the R & D and manufacturing base of the Energy and Power Institute of Huazhong University of Science and Technology, it is Also cooperate with China's State Key Laboratory of Optoelectronic.

Our company mainly engaged in the manufacturing of LED 7segment, connectors and other LED lighting products. The products are widely used in electrical appliances, computer, and lighting decorative and other fields. LED lighting products are with low energy, environmental protection and other features, which is in compliance with the global advocacy of energy saving and environment protection.

Our company covers an area of 7000 square meters, employs more than 500 people, including 120 professional R & D and technical staff. The workshop selects the advanced manufacturing system, strict quality control system and complete product inspection flow. The product has passed not only the related the ISO9001 authentication, but also the product authentication of RoHS, CE...
Company uphold the idea of managing continually, wholeheartedly and faithfully sercvice for new old customers with high technology and high quality.
