Categories
| Supplier: | Shenzhen LEDSolution Technology Co., Ltd. |
|---|---|
| Price: | Negotiable/Piece |
| Min Order: | 1/Square Meter |
| Quantity:: | |
| Trade Terms: | FOB |
|
|
| Prod Model: | LS-I-P8 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brightness: | 2, 000nits |
| Panel Material: | Epoxy Paint Coated Cold Rolled Steel |
| Multimedia Data Format: | DVI, Mpg, AVI, WMV, RM etc. |
| Data Interconnection: | UTP Cat 5/Optical Fiber |
| Mounting System: | Fixed with 4PCS M10 Bolts |
| Display Type: | LED Video Display |
| Tube Chip Color: | Full Color |
| Display Function: | Video Display |
| Scanning Mode: | 1/4 Scan |
| Certification: | ETL |
| Application: | Advertising |
| IP Rating: | IP43 |
| System Operating Platform: | WIN XP |
| Pixel Configuration: | 3in1 SMD |
| Pixel Pitch: | 8mm |
| Pixel Density: | 15,625DOT/M&Sup2 |
| Parameter | Unit | Value |
| Pitch | mm | 8 |
| Brightness | nits | 2, 000 |
| Color temperature | deg. K | 6, 500 |
| Viewing angle Horizontal (50% brightness) | deg. | 140(-70 ~ +70) |
| Viewing angle Vertical (50% brightness) | deg. | 140(-70 ~ +70) |
| Panel weight | kg | 45 |
| Panel width | mm | 1, 024 |
| Panel height | mm | 768 |
| Panel depth | mm | 150 |
| Panel area | sq. m. | 0.7864 |
| Panel material | Epoxy paint coated Cold rolled steel | |
| Operating temperature range | deg. C | -30 to +60 |
| Humidity operating | RH | 10% ~ 90% |
| Pixel type and configuration | R/G/B | 3in1 SMD |
| Resolution per panel | 128x96 | |
| Dot per panel | 12, 288 | |
| Dot per sq. meter | 15, 625 | |
| LED per sq. meter | 15, 625 | |
| Recommended minimum viewing distance | m | 8 |
| Recommended best viewing distance | m | 10~27 |
| Colors | 1, 073.7 millions | |
| Grey scale (linear) | Levels | 256 levels per color |
| Brightness control | Levels | 100 |
| Contrast ratio | 1, 000: 1 | |
| Processing depth | bit | 16 |
| Video frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 180~3, 000 |
| Input voltage (nominal) | VAC | 110 to 240 |
| Input power frequency | Hertz | 50 to 60 |
| Input power (max) | Watts /sq. m. | 610 |
| Input power (typical) | Watts /sq. m. | 244 |
| Lifetime (50% brightness) | Hours | ≥ 100, 000 |
| Red wavelength (dominant) | nm | 620~625 |
| Green wavelength (dominant) | nm | 520~525 |
| Blue wavelength (dominant) | nm | 470~475 |
| Multimedia data format | DVI, MPG, AVI, WMV, RM etc. | |
| Data interconnection | UTP Cat 5/Optical Fiber | |
| Mounting system | Fixed with 4pcs M10 bolts |
