Product Specifications
| Prod Model: |
SF-Z96A SF-Z72A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Installation: |
General Installation Meter |
| Display: |
Indicator |
| Usage: |
Meter for Industry and Home Use |
| Theory: |
Electronic Meter |
| Power Source: |
AC |
Product Description
Model: SF-Z96A, SF-Z72A
Measuring range: 0.1A/1A 0.2A/2A 0.3A/3A 0.4A/4A 0.5A/5A 1A/10A 5/5A
3 phase 3 wire Position: L1, L2
3 phase 4 wire Position: L1, L2, L3
Freq: 50Hz
Class: 1.5
Model: SF-Z96V, SF-Z72V
3 phase 4 wire Measuring range: 60V/100V, 80/150V, 100/200V, 150/250V, 250/400V, 300/500V.
Position: L1-L2, L1-L3, L2-L3, L1-N, L2-N, L3-N
3 phase 3 wire Measuring range: 100V, 150V 200V 250V 400V 500V.
Position: L1-L2, L1-L3, L2-L3
Accuracy: Class 1.5
Frequency range: 50HZ
Zhejiang tianqi electric Co., Ltd., with 10 years experience in electrical industry, is one of the leading manufacturer of distribution boxes and panel meters in China. Founded in China 1998, located in the beautiful land scape of the largest China bamboo sea in anji economic development zone which place is in the north of zhejiang, covers an area of 100, 000 square meters and has 500 employees.
T&j's product range consists of wall mounting enclosures, floor standing cabinets, stainless steel enclosures, plastic enclosures, terminal boxes, power distribution cabinets, floor standing modular cabinets, console systems, analog panel meters, digital panel meter, DIN rail panel meter, current transformer, shunt.
We also got the quality system certificate of CE, rosh, IP65 and ISO 9002 for our products. It has established the good commercial relations with America, west-europeam, east-Asia, Africa etc.
All kinds of electronics products and its accessories will be designed and manufactured according to the customer' s special requirement.
Sticking to the policy as "no quality, no future!
