Panoramic Elevator (square type) with Back Glass Wall
Product Specifications
| Prod Model: |
WO30 |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Drive: |
Vvvf Inverter Driving System |
| Traction Machine: |
Gearless Motor |
| Control: |
Monarch System |
| Buffer: |
Hydraulic Buffer |
| Car Position Indicator: |
LCD Display/DOT-Matrix Display |
| Driving Type: |
AC Elevator |
| Capacity: |
500-1000kg |
| Persons: |
6 - 10 |
| Speed: |
1.00 - 2.00m/s |
Product Description
A>. Advantage1. Our elevator control system comes from German technology, it is very precise and efficient but operation is simple, it can be mastered by engineers easily.2. Qualified and safe3. Steady and durable use4. ISO9001(quality management system) and ISO14001(environment management system) certifiicated5. Competitve price6. Best support in afterserviceB>. About our company:We have obtained Class A qualification of " Manufacture License of Special Equipment"and "Installation, Alteration, Repair & Maintenance License of Special Equipment".We have more than 200 employees including 40 technology engineers, they are working in such 8 departments: Technology dept, production dept, sales dept, quality checking dept, delivery dept, installation and maintenance service dept, afterservice dept, management dept and finance dept.Our main products include Passenger Lift, freight lift, panoramic lift, hospital lift, car lift, escalator and moving sidewalk.Up to Dec. 1, 2012, we have exported more than 1000units elevators and 800units escalators to more than 30 countries markets. Most of elevators and escalators which had been installed are running very well.We are a young enterprise and developing very fast, welcome you to visit our factory and we sincerely hope to cooperate with you. We will give you the best support both in price and in service.C>. Pictures for your reference:
Workshop, packing and delivery:
More designs you can choose:
If you have any query about the products, please feel free to contact me!Specifications in the following excel for your reference:| Panoramic lift |
| Load(Kg) | 800 | 1000 | 1350 |
| Rated Speed(m/s) | 1.0 | 1.5/1.6 | 1.75 | 1.0 | 1.5/1.6 | 1.75 | 2.0 | 1.0 | 1.5/1.6 | 1.75 | 2.0 |
| Door Size(mm) | 800 | 800 | 800 | 900 | 900 | 900 | 900 | 900 | 900 | 900 | 900 |
| Car Size(mm) | width | 1300 | 1300 | 1300 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| depth | 1680 | 1680 | 1680 | 1750 | 1750 | 1750 | 1750 | 2150 | 2150 | 2150 | 2150 |
| Shaft Size(mm) | width | 2300 | 2300 | 2300 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 |
| depth | 2200 | 2200 | 2200 | 2250 | 2250 | 2250 | 2250 | 2450 | 2600 | 2600 | 2600 |
| Machine Room Size (mm) or Machine room less | width | 2300 | 2300 | 2300 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 |
| depth | 4200 | 4200 | 4200 | 4200 | 4200 | 4200 | 4200 | 4200 | 4200 | 4200 | 4200 |
| height | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 |
| Overhead Height(mm) | 4800 | 4800 | 4800 | 4800 | 4800 | 4800 | 4800 | 4800 | 4800 | 4800 | 4800 |
| Pit Depth(mm) | 1900 | 2000 | 2000 | 2000 | 2100 | 2100 | 2200 | 2100 | 2100 | 2100 | 2200 |
Our company is a modernized and professional elevator & escalator manufacturer which integrates the design, development, manufacturing, sales, installation, and maintenance into a whole. We are becoming a R&D center for elevator & escalator now, and we have some cooperated & affiliated companies all over the world.
Our main products include Passenger lift, freight lift, panoramic lift, hospital lift, car lift, escalator and moving sidewalk. Elevator with machine room and machine room less, speed from 0.5m/s to 6m/s. Escalator with VVVF drive and smart sensor control. They are applicable for residence, business buildings, factories, shopping centers, airports, bus stations and other places.
Our elevator & escalator control technology comes from the United State and Germany, it is very precise and efficient but operation is simple, it can be mastered by engineers easily. And our mechanical design technology is advanced and can be fitting to different requirements from customers.
Most of our parts suppliers are the biggest parts manufacturer in China. i. e. Our gearless motor from XIZI Forward, Montanari, Bluelight, Torin; Our gear motor from XINDA, Torin; Our control system from Monarch, STEP, Bluelight; Our door operator from Shenling, Eshine etc., all of them are the leading enterprise in elevator and escalator parts industry in the world.
We have our own and professional import and export company to manage international business, it carries out sales activities in 25 oversea states and areas including Korea, Australia, South-East Asia, West-Asia, Middle-east, Europe, North and South America, Africa. Most of elevators and escalators which had been installed are running very well.
We are a young enterprise and developing very fast, welcome you to visit our factories and we sincerely hope to cooperate with you. We expect long terms cooperation with you and achieve a win-win situation.
