Product Specifications
| Prod Model: |
XTY-300LE11070 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Condition: |
New |
| Power: |
5.5kw |
| Place Of Origin: |
Jiangsu China |
| Brand Name: |
Xtpack |
| Certification: |
CE |
| Package: |
Wooden Crate |
| Automatic Grade: |
Manual |
| Strapping Mode: |
Welding Type |
| Driven Type: |
Hydraulic |
| Structure: |
Pressure Strapping |
| Application: |
Recycling Industry |
| Strapping Material: |
Flexible Baling Belt or Steel Wire |
| Packaging Type: |
Wooden Crate |
Product Description
UsageSpecially used for compressing the waste like food residue, paper, plastics and textile etc.Which widely applied by the vessels, hotels, resorts and factories etc.Feature1.Automatic chain bale ejector for quickly and easily ejecting the bales out from the machine2.Bottom liquid receiver is optional for collecting the liquid from the compressing materials3.The ram will stop running downwards when the feeding gate is opened which ensure the safety of the operation4.Equipped with independent emergency stop for safe operation5.Equipped with Euro and U.S standard anti-rebound gate structure which makes sure the safety of operation6.Special ram guides design makes the platen not slope because of uneven materials feedings during compression7.Equipped with NOK seals that from Japan means longer lifespan of the seals8.Equipped with A.M.C.Oil pipe joints that from Japan ensures the machine far away from oil leakage problems9.Equipped with integrated valves that from Taiwan, conveniently for the maintenance10.Peculiar combination of motor and pump with direct-crossed connection makes sure 100 percent concentricity, which replacing the common coupling connection so that extend the lifespan of the pumpSpecification| Model | SX-50LA6040 | SX-100LA6040 | SX-200LA8060 |
| Pressure | 5Tons | 10tons | 20tons |
| Feed Opening Size(L*H) | 600*400mm | 500*300mm | 700*400mm |
| Baling Chamber Height | 1000mm | 900mm | 1200mm |
| Bale Size(L*W*H,H is adjustable) | 600*400*(200-600)mm | 600*400*(200-600)mm | 800*600*(400-800)mm |
| Bale Weight | 20-40kg | 15-50kgs | 60-120kgs |
| Power | 1.5kw | 2.2kw | 3kw |
| Machine Weight | 450kg | 800kgs | 1000kgs |
| Machine Overall Dimension | 900*570*2240mm | 1000*800*2250mm | 1180*800*2550mm |
Product Show
WarrantyA:The Seller warrants that the baler machine will be of high-class quality of the material and free from defects in material and workmanship for a period of twelve (12) months from final performance acceptance.The Seller shall repair or replace at his own cost any equipment or parts thereof found to be defective during the guarantee period.If repair is caused by our machine itself, we will take responsible and the Buyer no needs to pay any money;If repair is caused by operator's improper use, we will not take responsible.We can provide technical communication and guidance at any time by telephone or mail.B:The guarantee for replaced parts which have been supplied during the guarantee period is also twelve (12) months.Delivery time35~40days after receiving 30% deposit
Production Process
Certification
Contact us:Tel:0513-86831977Fax:0513-86831900-804Website:Www.Xtbaler.Com
Jiangsu Xutian Environmental Protection Machinery Co., Ltd has been designing and manufacturing the waste materials compressing equipments for over 10 years, the company has established the good relationship with customers from all over the world.
The machine we produced can be applied for scraps, cartons, newspaper, PET bottles, plastic films, straws, non-woven fabrics, hard plastic baskets and other loose materials' pressing. XTPACK baling are CE certified and can supply you specialist solution for compressing waste materials by up to 95% into sorted, easily transportable bales.
In XTPACK plant, the motivated and highly-skilled professionals are dedicated to give you satisfied service. We delivery quality and also responsible for this after sale. We take services seriously and are committed to helping our customers in best way possible.
Following are series of our main products:
Small-sized & air-absorbing automatic balers.
Medium-sized automatic balers.
Large automatic balers.
30-60T horizontal baler with closed gate.
100T horizontal baler with closed gate.
Semi-auto horizontal baler for carton factory.
Vertical chamber lifting baler.
Vertical carton baler.
Small vertical baler.
Welcome to order, we will serve you.
