Parsun 5HP 4-Stroke Outboard Motor F5BMS

Name: Parsun 5HP 4-Stroke Outboard Motor F5BMS
Brand: china-manufacturer-directory.com
SKU: 757613085
Availability: InStock
Rating: 4.6 (125 reviews)

Supplier:	Suzhou Parsun Power Machine Co., Ltd.
Price:	US $ 599/Piece
Min Order:	5/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	F5BMS
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Engine Type:	4-Stroke, 1-Cylinders,Ohv
Displacement:	112cc
Full Throttle Rpm Range:	4000-5000
Ignition System:	TCI
Starting System:	Manual
Steering System:	Tiller Control
Gear Shift:	Forward-Neutral-Reverse
Max Fuel Consumption:	2.0L/H
Gear Oil Capacity:	100cc
Dry Weight:	24.5kg - 25.5kg
Fuel:	Gasoline Engine

Product Description

PARSUN FOUR STROKE 5HP OUTBOARD MOTORS FEATURES

1. Innovative TCI ignition system for easy starting
2. Twist grip throttle for easy maneuverability and safety
3. Safety lanyard/emergency shutoff
4. Thermostat controlled water cooling system for consistent engine temperature
5. Heavy duty aluminum propeller
6. Easy to monitor oil level gauge indicator
7. Convenient 1.3L integral fuel tank (complete with external fuel tank hook up)
8. Vibration reduction system
9. Start in gear protection
10. Shallow water drive
11. Ultra low emission, CE and EPA approved

Compact size and large handles make it highly portable and start-up is easy with CDI Ignition System. And on the water, you'll be delighted by the low fuel consumption, simple control, limited noise and vibration, and complete reliability.

	Model	Unit	F5BMS	F5BML
Item		Unit	F5BMS	F5BML
Overall length		mm(in. )	717(28.2)	717(28.2)
Overall width		mm(in. )	361(14.2)	361(14.2)
Overall height		mm(in. )	1029(40.5)	1156(45.5)
Transom height		mm(in. )	381(15)	508(20)
Weight		Kg	24.5	25.5
Full throttle operating range		r/min	4000~5000	4000~5000
Maximum output		Kw (HP) @r/min	3.6(5)@5000	3.6(5)@5000
Idling speed (Neutral)		r/min	900~1000	900~1000
Engine type			OHC	OHC
Cylinders			L2	L2
Displacement		cm 3	112	112
Bore × stroke		mmin	59*41	59*41
Ignition system			TCI	TCI
Control system			Tiller control	Tiller control
Starting system			Manual start	Manual start
Gear positions			Forward-Neutral-Reverse	Forward-Neutral-Reverse
Gear ratio			2.08 (27/13)	2.08 (27/13)
Trim and tilt system			Manual tilt	Manual tilt
Fuel tank capacity		L	integral 1.3	intergral 1.3
Maximum fuel waste		L /h	2.0	2.0
Engine oil capacity (Without oil filter)		L	0.5	0.5
Gear oil capacity		cm 3	100	100
Propeller options*		in	3-7.5" × 7"	3-7.5" × 7"
