Product Specifications
| Prod Model: |
SJ45/65 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max. Diameter: |
12-20mm |
| Extruder: |
Sj45/65 |
| Motor: |
Siemens |
| Electric Parts: |
Omron |
Product Description
PE Plastic Drip Irrigation Pipe Making Machinery for
Agriculture/Inside round dripper drip irrigation pipe
manufacturing machine
Line Model |
Screw Diameter |
L/D |
Production Scope |
Production Speed |
Nominal Power |
SJ-65 |
65mm |
33:1 |
8-20mm |
50m/min |
91KW |
SJ-45 |
45mm |
30:1 |
8-20mm |
20m/min |
37KW |
1, Application range:
The drip irrigation pipe can be widely used in water saving and irrigation of agricultural field (cotton, grapery, peanut and wheat etc.),
greenhouse, gardens etc. and mountain and hill region.
2, Characteristics:
1.The distance between emitters can be adjusted according to demands of different crops,it can be adjusted to same distance as well as regular pattern of different distances.
2.The emitter adopts unique design of circular arc flow path and has the characteristics of complete turbulent fluid,automatic washing and strong antiblocking.
3.The paving length is long and can reach 100 meters.
4.The mosaic column emitter type drip irrigation pipe can be used in plains as well as in hills and sloping fields.
5.One emitter has two or four outlets,which antiblocking capability is strong.
6.The pipe wall thickness can reach 1.2mm and has long service life.
-------------------------------------------------------------------------------------------------
3, Production line component:
No. Name |
Unit |
Quantity |
1. Extruder 65/30 |
sets |
One |
2. Head body |
sets |
One |
3.Emitters storage screening device |
sets |
One |
4.Emitters sorting conveyor |
sets |
One |
5.Emitters inlaid into the device |
sets |
One |
6. Plastic pipe forming and sizing device |
sets |
One |
7. Cooling tank |
sets |
One |
8. Traction machine |
sets |
One |
9.Automatic punching device |
sets |
One |
10. Finished coiler |
sets |
One |
11. Power-driven counter |
sets |
One |
12. PLC control console |
sets |
One |
13.Mixing and automatic feeding device |
sets |
One |
14.Cooling water supply and the circulatory system |
sets |
One |
----------------------------------------------------------------------------------------------------------------------------------------------------
4, Main technical parameters:
Specification of final product |
Φ12mm,Φ16mm,Φ20mm |
Wall thickness of final product |
0.5~1.2mm |
Dripper distance |
≥200m |
Production speed |
50m/min |
Main driving power |
45kw |
Max.extruding capacity |
120kg/h |
Heating power |
15kw |
Filter changing way |
Durable filter(patent) |
Total dripper supply power |
1.06kw |
Emitter supplying speed |
≤200 pcs/min |
Tractor driving power |
3kw |
Hole drilling speed |
≤200 pcs/min |
Winding driver |
12N.m*2 |
Water consumption |
3m3/h |
Air consumption |
2m3/h |
Installation power |
80kw |
Overall dimension |
30m*4.5m*3m
|
The company owns powerful technical strength, advanced technics, the best design and strict quality guarantee system, which owns a high repution in China rubber machinery industry.
The main products are plate vulcanizing press, open rubber mixing mill, banbury intensive kneader, extruder, rubber and reclaimed rubber machinery, within the (outside) tires complete set of machinery.The products have been sold to more than 20 provinces and cities in China and have been exported to more than 10 countries and areas.All of the products are designed visually by three-dimension CAD design, quickly built module, limited element analysis, analogue action and interfering inspection.The combination of three-dimension CAD system and internet guarantees the synchronization with internatinal advanced technology.The combination of three-dimension CAD and CNC numeral process center realizes the transit from traditional manufacture to modern three-dimension manufacture.At the same time, the company keeps good contact with several universities and research institutes.
The company takes"To live by quality, To develop by reputation, To innovate by science and technology, To keep improving all the time"as managing ideas, and insists on the principle of "Quality is the first, Reputation is the?First, Client is the first" that will provide you the best service.
