Supplier: | Shenzhen Noveled Technology Co., Ltd. |
---|---|
Price: | US $ 934/Square Meter |
Min Order: | 1/Box |
Quantity:: | |
Trade Terms: | FOB,EXW |
![]() |
Prod Model: | PH6 SMD3535 LED Display |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Module Size: | 288mm*288mm |
Cabinet Size: | 576*576*85mm (W*H) |
Colors: | 281 Trillion |
Brightness: | More Than 2000 CD |
Power: | AC220/110 ± 10%, 47~63Hz |
Refresh Rate: | More Than 1000Hz |
Processing: | 16 Bit |
Display Type: | LED Video Display |
Tube Chip Color: | Full Color |
Display Function: | Video Display |
Scanning Mode: | 1/8 Scan |
Certification: | CCC |
Pixel Configuration: | 1R,1G,1B |
Pixel Pitch: | 6mm |
Pixel Density: | 27,777 dots / m² |
Application: | Stage Performance |
IP Rating: | IP43 |
System Operating Platform: | Windows98/Me/2000/Nt/XP/Win7 |
Model | P6 | ||||
---|---|---|---|---|---|
Model No.: | LEDA-IR-P6 | ||||
Pixel Pitch | 6mm | ||||
LED Type | SMD3528 | ||||
Pixel Configuration | 1R1G1B | ||||
LED Driving Method | 1/8 scan | ||||
Module Pixel | 48*48 (W*H) | ||||
Module Size | 288*288MM | ||||
Cabinet Pixel | 96*96 (W*H) | ||||
Cabinet Size | 576*576*85mm (W*H) | ||||
Cabinet Weight | 10KG | ||||
Max. Power Consumption | ≤1000W/ | ||||
Ave. Power Consumption | ≤350W/ | ||||
Hor. Viewing Angle | 140° | ||||
Verti. Viewing Angle | 140° | ||||
Brightness | ≥2000 cd/ | ||||
Pixel Density | 27778/ | ||||
Protection Level | IP43(Front & Back) | ||||
Processing | 16 bit | ||||
Colors | 281 trillion | ||||
Refresh Rate | ≥1000HZ | ||||
Frame Rate | 60fps | ||||
Lifetime | 100,000 Hours | ||||
Power | AC220/110 ± 10%, 47~63Hz | ||||
Operating Temperature | -20ºC to +60ºC | ||||
Operating Humidity | 20% to 90% | ||||
Brightness Level | Manual 100 levels,automatically 16 levels | ||||
Certifications | CCC, FCC, CE, ROHS, UL, ETL |
