| Supplier: | Hebei Ruifeng Hardware Wire Mesh Co., Ltd. |
|---|---|
| Price: | Negotiable/Piece |
| Min Order: | 1/Meter |
| Quantity:: | |
| Trade Terms: | FOB |
|
|
| Prod Model: | 004 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Width: | 0.6-1.3m |
| Material: | Copper Wire |
| Application: | Decorative Mesh |
| Hole Shape: | Square |
Copper Wire Mesh | |||
Mesh/Inch | Wire Diameter(mm) | Aperture(mm) | Open Area % |
| 4 | 1.2 | 5.15 | 65.8 |
| 5 | 1.0 | 4.08 | 64.5 |
| 6 | 0.71 | 3.52 | 69.2 |
| 8 | 0.5 | 2.67 | 70.7 |
| 10 | 0.5 | 2.04 | 64.5 |
12 | 0.45 | 1.66 | 61.5 |
| 14 | 0.4 | 1.41 | 60.4 |
| 16 | 0.3 | 1.28 | 65.0 |
| 18 | 0.25 | 1.16 | 67.6 |
| 20 | 0.25 | 1.02 | 64.5 |
| 30 | 0.21 | 0.64 | 57.1 |
| 40 | 0.19 | 0.45 | 50.2 |
| 50 | 0.15 | 0.36 | 50.1 |
| 60 | 0.15 | 0.27 | 40.7 |
| 70 | 0.13 | 0.232 | 40.8 |
| 80 | 0.12 | 0.197 | 39.0 |
| 90 | 0.11 | 0.172 | 37.2 |
| 100 | 0.10 | 0.154 | 37.0 |
| 110 | 0.09 | 0.141 | 37.2 |
| 120 | 0.09 | 0.122 | 33.2 |
| 130 | 0.07 | 0.125 | 41.0 |
| 140 | 0.07 | 0.111 | 37.6 |
| 150 | 0.06 | 0.109 | 41.5 |
| 160 | 0.06 | 0.098 | 38.1 |
| 180 | 0.053 | 0.088 | 41.6 |
| 200 | 0.05 | 0.077 | 36.7 |
| (width of roll):0.60m-2.9m | |||
Mesh | Wire Dia.(mm) | Opening(mm) | ||
| SWG | MM | Inch | ||
| 6 | 22 | 0.711 | 0.028 | 3.522 |
| 8 | 23 | 0.610 | 0.024 | 2.565 |
| 10 | 25 | 0.508 | 0.020 | 2.032 |
| 12 | 26 | 0.457 | 0.018 | 1.660 |
| 14 | 27 | 0.417 | 0.016 | 1.397 |
| 16 | 29 | 0.345 | 0.014 | 1.243 |
| 18 | 30 | 0.315 | 0.012 | 1.096 |
| 20 | 30 | 0.315 | 0.0124 | 0.955 |
| 22 | 30 | 0.315 | 0.0124 | 0.840 |
| 24 | 0 | 0.315 | 0.0124 | 0.743 |
| 26 | 31 | 0.295 | 0.0116 | 0.682 |
| 28 | 31 | 0.295 | 0.0116 | 0.612 |
| 30 | 32 | 0.247 | 0.011 | 0.573 |
| 32 | 33 | 0.254 | 0.010 | 0.540 |
| 34 | 34 | 0.234 | 0.0092 | 0.513 |
| 36 | 34 | 0.234 | 0.0092 | 0.472 |
| 38 | 35 | 0.213 | 0.0084 | 0.455 |
| 40 | 36 | 0.193 | 0.0076 | 0.442 |
42 | 36 | 0.193 | 0.0076 | 0.412 |
| 44 | 37 | 0.173 | 0.0068 | 0.404 |
| 46 | 37 | 0.173 | 0.0068 | 0.404 |
| 48 | 37 | 0.173 | 0.0068 | 0.356 |
| 50 | 37 | 0.173 | 0.0068 | 0.355 |
| 60x50 | 36 | 0.193 | 0.0076 | |
| 60x50 | 37 | 0.173 | 0.0068 | |
60 | 37 | 0.173 | 0.0068 | 0.250 |
| 70 | 39 | 0.132 | 0.0052 | 0.231 |
| 80 | 40 | 0.122 | 0.0048 | 0.196 |
| 90 | 41 | 0.112 | 0.0044 | 0.170 |
| 100 | 42 | 0.102 | 0.004 | 0.152 |
| 120x108 | 43 | 0.091 | 0.0036 | |
| 120 | 44 | 0.081 | 0.0032 | 0.131 |
| 140 | 46 | 0.061 | 0.0024 | 0.120 |
| 150 | 46 | 0.061 | 0.0024 | 0.108 |
| 160 | 46 | 0.061 | 0.0024 | 0.098 |
| 180 | 47 | 0.051 | 0.002 | 0.090 |
| 200 | 47 | 0.051 | 0.002 | 0.076 |
Mesh | Wire Dia.(mm) | Opening (mm) | ||
| SWG | MM | Inch | ||
| 250 | 48 | 0.041 | 0.028 | 0.061 |
| 300 | 49 | 0.031 | 0.024 | 0.054 |
| 325 | 49 | 0.031 | 0.020 | 0.047 |
| 350 | 49 | 0.031 | 0.018 | 0.042 |
| 400 | 49 | 0.031 | 0.016 | 0.033 |
| 450 | 49 | 0.031 | 0.014 | 0.026 |
| 500 | 50 | 0.025 | 0.012 | 0.026 |
