Pin Pad with Magnetic Card Reader and Smart IC Card Reader

Pin Pad with Magnetic Card Reader and Smart IC Card Reader
Supplier: SZ KMY Co., Ltd.
Price: Negotiable/Piece
Min Order: 1/Piece
Quantity::
Trade Terms: FOB
contact supplier

Product Specifications

Prod Model: KMY3512B
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

Introduction
KMY POS Pin Pad model KMY3512B is a PIN Entry Device for POS system. This device upgrades the KMY3512 with magnetic card and IC card reader function. It adopts MK/SK key management solution and TDES PIN encryption solution. With all these advanced technical features, it can provide a secure PIN entry service for all kinds of application.

Key Features
Magnetic/IC card reader option
DES/3DES encryption algorithm
Master key/Session key management
Ergonomic design for handhold
Large graphic display with Backlit
CPU 80MHz 64MFlash 32M SDRAM
Display 20*5 English character LCD with backlight
Keys 12 number keys,4 function keys
More than 2,000,000 times
Key pressure 3~5N, range 1.0mm
Beeper Internal beeper
PIN Shield 20mmplastic shield optional
Magnetic card reader Supports 1,2 or 2,3 track, ISO7812-2
IC card reader supports IC card ISO7816
Communication USB
Power Voltage: 5V +/- 20%
Current: less than 250mA
Dimensions 160x100x60(mm)
Weight 300g
Operating Environment Temperature : -25~65
Humidity : up to 80%, non-condensing
Life Time More than 10 years
MTBF More than 5000 hours
Security Standard DES,3DES encryption algorithm
Master key/Session key management
The key and the program erased for abnormally open,
ISO9564, IBM3624, ANSI X9.8, ANSI X9.9, ANSI X9.19
SZ KMY Co., Ltd. is a leading high-tech company dedicated to R&D, manufacturing, marketing and services in customized self-service computing platforms and related metal keyboard/EPP//POS peripherals. KMY product range covers from self-service kiosk, Metal keyboard/keypad/EPP and POS peripherals, to more other related products. We can provide our customer with one-stop solutions according to their different demands.

KMY defines its strategic goal as "becoming a worldwide leader in the self-service world and achieving leapfrog evolution from excellence to preeminence". To this end, kmy will adhere to its core value: "responsibility makes perfection"and spare no effort to improve its competitiveness by endless development. With its well-built operation system, outstanding organization structure and fully-trained personnel, kmy aims at building an internationalized designer and manufacturer of self-service terminal. The products and solutions are popular both in the domestic and global markets over 100 countries, including America, Europe, Asia, Africa, and the Middle East and won strong reputation in this industry.
