COMPANY PROFILE
Guangzhou AirHorse Compressor co., ltd is the professional manufacturing and exporter. We are specialized in air compressor research, development and production. The main products including screw air compressor, piston air compressor and air dryer etc. With the advanced design, high reliability, low noise, long running life time, our products are widely used in power generation, semi conductor, shipping, ship building, oil field, rubber, food, pharmacy, package, electronic, communication, cement, glasses, chemical, textile, papermaking, gas, oil refining etc.
With 30 years's profound researches and experience in this line, and the join of high- technical from Germany and Italy, We produce the very good quality screw air compressor and our goods were selling more than 100 countries and area. We are famous with " Superior quality, competitive price and high-grade service".
We have obtained the approval of ISO9001-2000 international quality management system, ISO14001 Enviroment management system authentication, CE quality system, UL quality system ASME quality system etc.
? Features of the portable Screw Air compressor
1. The piston air compressor can be continuously operated for 16 hours.
2. It is reliable, easy to install and economical.
3. The piston air compressor has a cast iron compressor pump, totally enclosed belt guard, and industrial grade motors.
4. It has an automatic unloading device that matches output to system requirements to reduce power consumption costs.
5. The piston air compressor is designed to operate with low speed.
6. It uses the most popular design in the market, and it is mature, reliable and easy to maintain.
7. It offers a simple structure, high efficiency and is cost=effective.
8. The piston air compressor is made with top quality material and has exquisite workmanship.
9. It offers a powerful head design, low speed, stroke length and longer service life than the similar products.
10. It adopts the ring valve design and the valve material imported from Japan and Sweden, which greatly increases the performance and service life of air valve.
11. The piston air compressor uses a piston ring from Taiwan Riken that is durable and non-oil.
12. The crank shaft by high-frequency quenching, enhances the wear resistance of the product.
13. The oil separator structure design of the front cover offers low fuel consumption and in the long term keeps the body clean.
14. In volume control, there are gas and electronic automatic control types, gas and electronic dual-use type, and four types of intelligent control. Depending on the gas situation, it will automatically switch between electric control and pneumatic control.
15. The piston air compressor is CE certified, and is manufactured under ISO standard. So customers can feel secure in placing orders.
16. We offer a one year full machine warranty.
? Special Customized Service
1). Full OEM
Quantity: At least 5 pcs
In this plan, we will do all the changes (Colour, name plate and logo) as your need, and will not charge extra fee.
2). Half OEM
Quantity: No limit
Under this program, we can make the necessary alteration (name plate and logo). But we will charge some extra fee for the name plate, as the name plate factory has the MOQ.
3). Logo OEM
Quantity: No limit
Only the logo will be changed to yours, and no extra fee will be charged.
? Engineer Oversea Service
We are available to send our engineer for aboard service. Only need you to arrange the accommodation, transportation and translator. Extra cost each will be discussed based on local price level.
? Rich experience for difference elec-voltage
415V 50HZ to some Asia countries
220V 60HZ to some South America contries
380V 60HZ to some Asia or North America countries
380V 50HZ is our most popular items
| Piston Air Compressor |
| Model | Motor Power | Electricity | Speed | Air Flow | Cylinder
(diameter*piece) | Working Pressure | Tank | Dimension
L*W*H | Weight |
| (KW) | (HP) | (V/ph/Hz) | (rpm) | (L/min) | (CFM) | (mm*pcs) | (bar) | PSI | (L) | (cm) | (kg) |
| DWT-Z508 | 0.75 | 1 | 220/1/50 | 810 | 36 | 2 | 51*1 | 8 | 116 | 33 | 70*37*66 | 48 |
| DWT-V1708 | 1.5 | 2 | 220/1/50 | 1080 | 170 | 6 | 51*2 | 8 | 116 | 75 | 103*49*78 | 80 |
| DWT-V2508 | 2.2 | 3 | 220/1/50 | 1000 | 250 | 9 | 65*2 | 8 | 116 | 100 | 110*51*85 | 93 |
| DWT-W3608 | 3 | 4 | 380/3/50 | 1000 | 360 | 13 | 65*3 | 8 | 116 | 120 | 123*49*88 | 120 |
| DWT-W3612 | 3 | 4 | 380/3/50 | 1000 | 360 | 13 | 65*2 51*1 | 12 | 181 | 100 | 123*49*88 | 120 |
| DWT-V6008 | 4 | 5.5 | 380/3/50 | 1000 | 600 | 22 | 80*2 | 8 | 116 | 150 | 135*50*95 | 160 |
| DWT-V6012 | 4 | 5.5 | 380/3/50 | 1000 | 600 | 22 | 80*1 65*1 | 12 | 181 | 150 | 135*50*95 | 160 |
| DWT-V6708 | 5.5 | 7.5 | 380/3/50 | 1000 | 670 | 24 | 90*2 | 8 | 116 | 160 | 140*52*97 | 170 |
| DWT-V6712 | 5.5 | 7.5 | 380/3/50 | 1000 | 670 | 24 | 90*1 80*1 | 12 | 181 | 160 | 140*52*97 | 170 |
| DWT-W6708 | 5.5 | 7.5 | 380/3/50 | 1000 | 670 | 24 | 80*3 | 8 | 116 | 180 | 155*56*103 | 210 |
| DWT-W6712 | 5.5 | 7.5 | 380/3/50 | 1000 | 670 | 24 | 80*2 65*1 | 12 | 181 | 180 | 155*56*103 | 210 |
| DWT-W9008 | 7.5 | 10 | 380/3/50 | 980 | 900 | 32 | 90*3 | 8 | 116 | 250 | 158*58*106 | 225 |
| DWT-W9012 | 7.5 | 10 | 380/3/50 | 980 | 900 | 32 | 90*2 80*1 | 12 | 181 | 250 | 158*58*106 | 225 |
| DWT-W12008 | 7.5 | 10 | 380/3/50 | 780 | 1200 | 43 | 100*3 | 8 | 116 | 400 | 167*67*123 | 380 |
| DWT-W16008 | 11 | 15 | 380/3/50 | 900 | 1600 | 57 | 100*2 90*1 | 8 | 116 | 450 | 170*70*126 | 436 |
Guangzhou AirHorse Compressor Co., Ltd is the professional manufacturing and exporter. We are specialized in air compressor research, development and production. The main products including screw air compressor, piston air compressor and air dryer etc. With the advanced design, high reliability, low noise, long running life time, our products are widely used in power generation, semi conductor, shipping, ship building, oil field, rubber, food, pharmacy, package, electronic, communication, cement, glasses, chemical, textile, papermaking, gas, oil refining etc.
With 30 years's profound researches and experience in this line, and the join of high-technical from Germany and Italy, We produce the very good quality screw air compressor and our goods were selling more than 100 countries and area. We are famous with " Superior quality, competitive price and high-grade service".
We have obtained the approval of ISO9001-2000 international quality management system, ISO14001 Enviroment management system authentication, CE quality system, UL quality system ASME quality system etc.
