Product Specifications
| Prod Model: |
HH-204 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Surface Flatness: |
Lambda/10@633nm |
| Surface Quality: |
10-5 ~ 20/10 |
| Parallelism: |
<3 Arcmin |
| Diameter Tolerance: |
+0.00/-0.10mm |
| Thickness Tolerance: |
+/- 0.2mm |
| Clear Aperture: |
>90% of Central Diameter |
| Coating: |
Optional |
| Bevel: |
0.30mm X 45° |
| Material: |
Optical Glass |
| Shape: |
Round |
| Type: |
Round |
Product Description
Gerneral purpose plane windows
Flat polished surfaces
Laser finish both sides
Apply any anti-reflecting coating
These general purpose plane windows are polished to lambda/10 flatness except where indicated otherwise. They are intended for for transmissive use and are parallel to better than 3 arcmin or 10 arcsec. Select a coating appropriate to your application or contact us with your special coating requirements.
Parameters:
Surface Flatness: λ /10@633nm
Surface Quality 10-5 ~ 20/10
Parallelism <3 arcmin
Diameter Tolerance +0.00/-0.10mm
Thickness Tolerance ± 0.2mm
Clear Aperture >90% of central diameter
Coating Optional
Bevel 0.30mm x 45°
UV fused silica window
Surface Flatness λ /10@633nm
Surface Quality 10-5 scratch and dig
Parallelism <3 arcmin
Diameter Tolerance +0.00/-0.10mm
Thickness Tolerance ± 0.2mm
Clear Aperture >90% of central diameter
Coating Optional
Bevel 0.30mm x 45°
CaF2 window
Surface Flatness λ /4@633nm
Surface Quality 20/10-40/20
Parallelism <3 arcmin
Diameter Tolerance +0.00/-0.10mm
Thickness Tolerance ± 0.2mm
Clear Aperture >90% of central diameter
Coating Optional
Bevel 0.30mm x 45°
