Product Specifications
| Prod Model: |
AK-S Series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
PLC Control System Stick Labeler Machinery |
| Material: |
Stainless Steel |
| Control: |
PLC |
| Quaility: |
High |
| After-Sales Service: |
Provided Engineers Available to Service Machinery |
| Automatic Grade: |
Automatic |
| Type: |
Automatic Labeling Machine |
| Driven Type: |
Electric |
| Packaging Type: |
Bottles |
| Packaging Material: |
Plastic |
| Applicable Industry: |
Alcohol and Tobacco |
| Application: |
Hair Care Products |
Product Description
PLC Control System Stick Labeler Machinery
Character:
1. This automatic labeling machine is suitable for pharmacy, food, beverage, daily chemical industry etc.
2. Single side, double, and lateral labeling of all kinds of quadrate & flat bottles.
3. Machine adopts PLC process control, photo-electricity bottle checking and label delivery.
4. The labeling machine production efficiency is high, labeling is precise and reliable, operation is convenient.
5. Play system: It depends on 3-5 pole motor driving, electronic control speed, full automatic transmission device, electricity source place combine with highly precise density steel star gear, include automatic suited machinery safety device.
Features:
1. Whole bottle labeling machine agreat quantity of stainless steel and good-quality ulminium alloy, reasonable fracture, compact, convenient to adjust;
2. Shrinkage film volume label rack, match with adjustable device, convenient to adjust according to differ volume label 5~10paper tube.
3. Simply installation, then can convenient for square and round bottle.
4. No need of instrument, rotary mechanism is convenient to adjust, apply to differ bottle type.
5. Unique sleeve labelling method, adopt to pressing sleeve labelling method, not only convenient but also reasonable.
6. Auto controlling feeding system, level-off shrinkage film materials and regulate/adjust strain simultaneity.
7. Unique design knife plate, within specification scope, can avoid changing knife base, knife changing is quick and conveniently.
8. Middle guide-pole clip system, mould changing is more quick, no need any instrument.
9. Stainless steel electric equipment controlling case, controlling adopt to Japanese OMRON PLC.
Detail picture of labeling machine:
Packaging of labeling machine:
|
Production capacity |
According to the requirements of customers |
|
Label specification |
φ30~90mm |
|
Bottl&can diameter |
φ28~90mm |
|
Label length |
30~250mm |
|
Label thickness |
≥0.035mm |
|
Label material |
PVC/PET/OPS |
|
Main machine power |
4KW(220V,50HZ) |
|
External size |
2100×900×2200mm |
|
Weight |
480kg |
