Product Specifications
| Prod Model: |
AF-10MR-E |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
PLC --Programmable Logic Controller AF-10MR-E
AF-10MR-E AC14-20V/DC12-24V 6 Point AC/DC digital input 4 points relay output
This model is a DC/AC power supply, with digital input, 6 points AC/DC input, 4 points relay output
Exquisite and compact design
Multi-functional, easy operating, convenient, easy learning
Operation temperature -20-70 Timers 127
Storage/Transportation -40-70 Counters 127
ProtectionIP20
Function blocks: 127
Interference Regulation: EN55011(B Class) RTC time intervals127
RTC accuracy: MAX ± 5S/day
Storage capacity64K
CertificateCE
Insulation Intensity: IEC1131
Installation: Use a standard DIN rail or screw for installation Dimensions90*71*58Unitmm
Power supply
Rated voltageAC14-20V/DC12/24V
Main voltage operation rangeAC12-24V/DC10-28V
(Output full-load)Typical 3W
AC/DC24V consumption Typical 125mA
Digital input
Signal 0DC 0-5V Input current<0.2mA
Signal 1AC12-24V/DC 10-24V Input current<1mA
Digital output
Output type: Relay output
Wiring insulation: Yes
Points per set1
Continuous current max valueMAX 10A
Switch frequency
Mechanism 10Hz Resistor load 2Hz
Inductive load 0.5Hz
|
This model is a DC/AC power supply, with digital input, 6 points AC/DC input, 4 points relay output |
|
|
|
|
|
Exquisite and compact design |
|
|
|
Multi-functional, easy operating, convenient, easy learning |
|
|
|
|
|
|
Operation temperature: :-20C degree-70C degree |
|
Timers :127 |
|
|
Storage/Transportation -40C degree-70C degree |
|
Counters :127 |
|
|
|
Protection:IP20 |
|
Function blocks : 127 |
|
|
|
Interference Regulation: EN55011(B Class) |
|
RTC time intervals:127 |
|
|
|
RTC accuracy: MAX ±5S/day |
|
Storage capacity:64K |
|
|
|
Certificate:CE |
|
Insulation Intensity: IEC1131 |
|
|
|
Installation: Use a standard DIN rail or screw for installation |
|
Dimensions:90*71*58(Unit:mm) |
|
|
Power supply |
|
|
|
Rated voltage:AC14-20V/DC12/24V |
Main voltage operation range:AC12-24V/DC10-28V |
|
|
|
(Output full-load):Typical 3W |
AC/DC24V consumption: Typical 125mA |
|
|
Digital input |
|
|
Signal 0:DC 0-5V |
Input current:<0.2mA |
|
|
Signal 1:AC12-2
4V/DC 10-24V |
Input current:<1mA |
|
|
Digital output |
|
|
|
Output type: Relay output |
Wiring insulation: Yes |
|
|
Points per set:1 |
Continuous current max value:MAX 10A |
|
|
Switch frequency |
|
|
|
Mechanism: 10Hz |
Resistor load: 2Hz |
|
|
Inductive load: 0.5Hz |
|
|
