Product Specifications
| Prod Model: |
LD-1008P |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Enterprise, Soho |
| Firewall: |
Without Firewall |
| Transfer Rate: |
10/100Mbps |
| Ports: |
8 |
| Port Structure: |
Modular |
| Network: |
All Nets |
| Output Type: |
DC |
| Compliant: |
IEEE802.3, IEEE 802.3u and IEEE802.3af |
| Certification: |
CB |
| Use: |
Wired |
Product Description
This POE model is 8-port/8 PoE Port Un-managed PoE Ethernet Switch for IP Camera, Built-in 48V DC Power Supply
1. With PoE injector
2. Descriptions:
Designed for residential buildings in the corridor-level broadband switching equipment, for the edge of the access and LAN to provide high-quality network connections
Case-shaped device with a chassis of 1U high
Provides 8 10/100 base-TX ports
Provides 4/8 PoE injector
3. Features:
Conforms to IEEE802.3, IEEE 802.3u and IEEE802.3af
Provides eight 10/100 base-TX ports
Provides 4/8 PoE injector and built-in AC power
High back-plane bandwidth 1.8Gbps
IEEE802.3 X flow control
Surge protection for power port and data ports
EMI standards, compliant with FCC, CE class B
4. Specifications:
4.1 Summarize:
Fixed port: 8/10/100 base-TX ports
LED indicators: PWR, PoE, Link/Act and VLAN LED
Input voltage: 100 to 240V AC, 50/60Hz
Power consumption: 70/130W (65/125W for PoE)
Operating temperature: 0 to 40° C
Storage temperature: -10 to 70° C
Relative humidity: 20 to 85% (non-condensing)
Thermal methods: Built-in noiseless fan
Switching capacity: 1.8G
Mac address table: 1K
Traffic control IEEE 802.3X full-duplex flow control
4.2 PoE:
PoE port: 4/8 10/100/1000 base-TX ports
PoE standards: IEEE802.3af, per port 15.4W
Pin assignment: V+ (RJ45 pin 4, 5), V- (RJ45 pin 7, 8)
