CHANGHONG MACHINE IS FAMOUS BRAND IN CHINA.
CE CERTICIATE, EUROPEAN QUALITY, GERMANY TECHNOLOGY! !
We are the professional manufacturer of flexo printing machine
Ruian Changhong Printing Machinery Co., Ltd is a professional manufacturer Of Kinds Flexo Printing Machines, like non woven fabric, paper, plastic film and other related products
We Have Many Kinds Printing Machines, Normal Speed Printing Machine 50 Meter/min, Middle Speed 80Meter/min and higher speed Printing Machine which Over 150METER/MIN
Machine size: Standard size: 600-1200mm
Also we can make 1500mm, 1800m, 2000mm, 2400mm, 3200mm.
Offer your details, Make machines only belongs to you.
1) Good Quality, Well and timely Service, Competitive Price
2) Certificate: CE Certificate
3) One Year Warranty For Free, Long Life Service.
4) Tension Controller, EPC, Ceramic Rollers, Doctor Blade
5) Taiwan Motors
6) synchronous belt drive instead of gear drive
I. Procedure:
Unwind System ---- Edge Position Controller ----Flexographic Printing Machine----Dry System----Automatic Tension System---- Rewind System
II. Characteristics
1. Take it easy, accurate color, long life.
2. Use motors, variable frequency speed control, saving electricity, small running fluctuations.
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink.
4. Use special diagonal-tooth gear, accurate printing size.
5. Two sets of heating devices, including central heating and constant temperature control system for group control.
6. Lowroller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium.
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced.
8 With cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. Print produce are clear and good arrangement quality.
10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll
III. Main parts of printing machine
1)Automatic tension control and magnetic power
2)With EPC
3)Air shaft
4)Cylinder stator
5)Auto Loading
6)Panasonic Inverter
7)Schneider Swtiches
8)Chint Relay
9)Chromed Cylinder
| Printing width Item | 800mm | 1000mm | 1200mm | 1400mm | 1600mm | 1800mm | 2000mm | 2200mm |
| Printing color | at your choice/ 6 special color |
| Printing length | 7.5"-40"/7.5"-50" |
| Printing plate lifting system | Pneumatic/Hydraulic press control |
| Mechanical speed | 80m/min |
| Printing speed | 60m/min |
| Anilox cylinder | Metal: 10DK-100DK(Germany) |
| Register precision | Longitude:±0.20mm Transverse:±0.20mm |
| Rewinder/Unwinder DIA | ø 600mm/ ø 800mm/ ø 1000mm/ ø 1200mm |
| Master motor | 4KW | 5.5KW | 7.5KW | 11KW |
| Unwinder motor | 1.1 KW×2 | 1.5 KW×2 | 2.2 KW×2 | 3.0 KW×2 |
| Rewinder motor | 1.5 KW×2 | 2.2 KW×2 | 3.0 KW×2 | 3.7KW×2 |
| Electrical header | 27KW | 30KW | 33KW | 36KW | 40KW | 45KW | 48KW | 52KW |
| Blower of header | 0.75KW×2 | 1.1KW×2 | 1.1KW×2 | 1.5KW×2 | 1.5KW×2 | 1.5Kw×2 | 2.2KW×2 | 2.2KW×2 |
| Blower of nature wind | 0.75KW | 1.1KW | 1.1KW | 1.5KW | 1.5KW | 1.5KW | 2.2KW | 2.2KW |
| Inking motor | 370W | 370W | 370W | 370W | 370W | 750W | 750W | 750W |
| Master frequency converter | 5.5KW | 5.5KW | 7.5KW | 7.5KW | 11KW | 11KW | 15KW | 15KW |
| Bearing | Japan(NSK) |
| Unilateral bearing | ASNU(Germany) |
| Weight | 10620Kg | 10920Kg | 11330Kg | 11630Kg | 12100Kg | 12500Kg | 13000Kg | 13850Kg |
| Master power | 42KW | 45KW | 50KW | 55KW | 63KW | 68KW | 74KW | 82KW |
Located in Ruian, Zhejiang, Ruian Changhong Machinery Factory is a manufacturer of printing machinery which specializes in the production of flexographic printing machines.
Over the years, we have been sticking to the enterprise concept that the management of an enterprise is the management of talents. Every staff member takes "customer satisfaction as the supremacy. with our confidence and ceaseless efforts, we firmly believe that our enterprise will have a more splendid future!
Changhong Machinery Factory is mainly engaged in design and manufacturing of printing machines. At present, with the Project Department, the Technical Service Department and the New Product Research Center which all boast tremendous strength, it is capable of independently developing new flexographic printing machines. Machinery products developed in the recent years, such as high-speed computerized chromatic flexo printing machines, high-speed cascading flexo printing machines and in-line flexo printing machines, are exported to various regions and countries including Eastern Europe, North America, South America, Southeast Asia, Russia, Africa, Middle East, etc., which have received good market feedback and positive comments from customers.
The products of Changhong mainly feature stable and simple operation, good durability, simple maintenance, even inking, strong stability and long service life.
