Polymer Filter for Plastic Extrusion Machine
Product Specifications
| Prod Model: |
GM-R series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Function: |
Polymer Melt Filter |
| Raw Material: |
38CrMoAl |
| Suitable Materials: |
PP/PE/PS/ABS/EPE/EPS/XPS and So on |
| Size: |
Different Size to Be Matched with Extruders |
Product Description
Polymer filter for plastic extrusion machineSpecification
1) continuous type,no interrupt production
2)Air venting system help to improve the quality of the product
3)Material leak-free mold
Features included1)This series of polymer filter, is aslo called hydraulic screenchanger,consists of four independent breaker plates, each with openings of same diameter and screen pattern. The rotation of these specially treated alloy metal plates gives superior sealing ability and durability. This type of screen changer has slight flow fluctuation during screen changing. It can guarantee a continuous and stable extrusion production.
2)Breaker plates move in the same direction one by one, improved filtration performance, convenient to clean.
3)Equipped with preheating and ventilation design to minimize the effect of possible temperature, pressure, melt flow fluctuation on polymer during screen changing process.
Finished products show
Benifits of this GM-R series of polymer filter/hydraulic screen changer
No rupture on film and filament production and changing the screen without stopping the production
It can be used for pelletizing, pipe, plate, sheet, EPE, EPS, , XPS extruded plate, PVB film, board, squeeze net, BOPET / BOPP, filament.
Years of practical applications show that the significantly effect of PE, PP, drawing, EPE, EPS production, improved products can meet the drawing and spinning of PET and other Technical data
Type |
Screen D&A
| (mm)
overall dimension |
Heating power
(KW)) |
Output
(kg/h) |
| (mm) | (CM²) | L | W | H | L1 |
|
|
| GM_R-70 | Φ70 | 38 | 270 | 170 | 240 | 850 | 3.2/4.5 | 50-250 |
| GM_R-100 | Φ100 | 78 | 375 | 200 | 280 | 1000 | 4.8/7.0 | 320-480 |
| GM_R-120 | Φ120 | 113 | 435 | 240 | 320 | 1150 | 6.0/8.4 | 320-600 |
| GM_R-150 | Φ150 | 176 | 525 | 260 | 320 | 1400 | 7.2/9.5 | 420-900 |
| GM_R-200 | Φ200 | 314 | 700 | 280 | 380 | 1750 | 8.2/11.0 | 500-1100 |
:,.
Note: The specifications are subject to change without prior notice. |
Zhengzhou Great Machinery Co., Ltd is a company focus on the design and research of hydraulic screen changer, melt pump and extrusion dies. Gmach is a young company but has a large number of senior technicians, the deep technical background and full of passion work team determine it is standing on a high starting point. We do not just supply you the products, but also provide the solution to solve the problem.
We are committed to provide you the best products with ever improving design, strict production and quality control. Strong professional technical team provides you the perfect pre-sales and post-sales services.
Gmach's mission: Commit to plastic extrusion field, develop the environment friendly product, create a well-known brand at home and abroad
Now we have the following products
1, Plate type hydraulic screen changer GM-SSP series
2, Double plate type screen changer GM-DSP series
3, Double piston type continuous screen changer GM-DP-R series
4, Plate type continuous screen changer GM-R series
5, Automatic screen changer GM-ACB series
6, Large filtration area continuous screen changer GM-DP-L series
7, Spining pump
8, extrusion melt gear pump
9. Chemical pump
10, plastic recycling machine
11, plastic granules making mahcine pelletizing line
