Polymeric Surge Arrester/Polymeric Lightning Protector/Polymeric Lightning Arrester

Name: Polymeric Surge Arrester/Polymeric Lightning Protector/Polymeric Lightning Arrester
Brand: china-manufacturer-directory.com
SKU: 766953815
Availability: InStock
Rating: 4.5 (91 reviews)

Supplier:	Zhejiang Laurence Power Equipment Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	Polymeric surge arrester
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	Grey
Structure:	Zinc Oxide Arrester
Installation:	Parallel Arrester
Material:	Polymeric

Product Description

Basic Info.
Origin: Yueqing, Wenzhou, Zhejiang, China
Brand Name: as customer's requirement
Packaging: standard package or cilent's requirment

Features:
Reliability and excellent protection based on years of experience and expertise in surge protection.
Good anti-moisture capability, resistant to pollution.
GIS metal oxide surge arrester, composite metal oxide surge arrester and porcelain metal oxide surge arresters are available.
Long life and lightweight.
Easy installation and maintenance.
Good sealing capability to ensure reliable operation.
High energy absorption ability.

Product range:
Surge arresters 0.22kV~220kV

Technical Specification:

Type	MOA Rated voltage KVrms()	MCOV KV(rms)	Current impulse Residual Voltage			2ms Rectangular current impulse withstand A(crest)	4/10μs high current impulse withstand KA(crest)
Type	MOA Rated voltage KVrms()	MCOV KV(rms)	1/4μs Lightning current impulse KV(crest)	8/20μs Lightning current impulse KV(crest)	30/60μs Switching current impulse KV(crest)	2ms Rectangular current impulse withstand A(crest)	4/10μs high current impulse withstand KA(crest)
YH5W-3	3	2.55	11.3	9	8.9	150	65
YH5W-6	6	5.1	22.6	18	16.8	150	65
YH5W-9	9	7.65	33.7	27	23.8	150	65
YH5W-10	10	8.4	36	30	23	150	65
YH5W-11	11	9.4	40	33	30	150	65
YH5W-12	12	10.2	42.2	36	27	150	65
YH5W-15	15	12.7	51	45	38.5	150	65
YH5W-18	18	15.3	61.5	54	.2	150	65
YH5W-21	21	17	71.8	63	54.2	150	65
YH5W-24	24	19.5	82	72	62	150	65
YH5W-27	27	22	92	81	69.8	150	65
YH5W-30	30	24.4	102	90	79	150	65
YH5W-33	33	27.5	112	99	86.7	150	65
YH5W-36	36	29	123	108	92.4	150	65

Zhejiang Laurence Power Equipment Co, . Ltd. Is Located at Weishiyi Road, Economic Zone Yueqing Wenzhou City Zhejiang P. R. China which is specialized in producing Electric power fitting, Guy grip, make off, Dead end Clamp, P. G. Clamp, Surge arrester, Dropout fuse isolator, Varistor etc. And have been supplying various products to overseas customers for the electrical engineering industry, including Zinc Oxide Varistors, Arresters, insulators, Fuse Cutouts, Transformers, Line hardware and so on.

High quality and favorable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.

Our products have being service in more than 20 countries power system.

We just focus on ELECTRIC POWER, and service the WORLD POWER.
