Popular XCMG 37ton Hydraulic Crawler Excavator XE370C with 1.6m3 bucket
1. Operation weight: 36400kg
2. Rocky bucket 1.4 m3
3. Max. Digging height: 10423mm
4. Original KAWASAKI hydraulic system
5. Engine: Japan ISUZU 184kw
6. Original KAWASAKI electronic system
7. Cabin with A/C, ROPS/FOPS
8. With break hammer
XCMG hydraulic crawler excavator XE370C with Japan ISUSU engine and has operation weight of 36400kg. It has strong performance in building construction and can be used in mine with hydraulic hammer to break stones into small ones for further processing in crushing plant.
Japan KAWASAKI hydraulic system and electronic system has provided XE370C excavator with reliable and excellent performance.
| Model | | | Unit | XE370C |
|---|
| Operating weight |
|
| kg | 36600 |
| Standard bucketcapacity |
|
| m 3 | 1.6 |
| Engine | Engine Model | --- | ISUZU AA-6HK1XQP |
| Type | Direct injection | --- | √ |
| Four strokes | --- | √ |
| Water cooling | --- | √ |
| Turbo charged | --- | √ |
| Air to air intercooler | --- | √ |
| No. of cylinders |
| --- | 6 |
| Rated power/speed |
| kW/ r/min | 184/2000 |
| Max. torque/speed |
| N.m | 872.8/1700 |
| Displacement |
| L | 7.79 |
| Main data | Travel speed |
| km/h | 5.4/3.2 |
| Max. gradeability |
| % | 58 |
| Swing speed |
| r/min | 10.1 |
| Ground pressure |
| kPa | 67.8 |
| Bucket digging force at power max. |
| kN | 242 |
| Arm crowd force at power max. |
| kN | 174 |
| Hydraulic | Main pump |
| -- | 2Plunger pump |
| Rate flow |
| L/min | 2x280 |
| Max pressure of system |
| MPa | 31.5/34.3 |
| Max pressure of travel equipment |
| MPa | -- |
| Max pressure of swing equipment |
| MPa | -- |
| Pilot press setting |
| MPa | 3.9 |
| Oil & Fuel refilling | Fuel tank capacity | L | 600 |
| Hydraulic tank capacity | L | 320 |
| Engine lubrication | L | 28 |
| Dimensions | Overall length | mm | 11105 |
| Overall width | mm | 3190 |
| Overall height | mm | 3300 |
| Overall width of upperstructure | mm | 2960 |
| Track length | mm | 5070 |
| Overall width of undercarriage | mm | 3190 |
| Standard track shoe width | mm | 600 |
| Track length on ground | mm | 4040 |
| Track gauge | mm | 2590 |
| Clearance under counter weight | mm | 1197 |
| Ground clearance | mm | 500 |
| Tail swing radius | mm | 3450 |
| Working Range | Max. digging height | mm | 10445 |
| Max. dumping height | mm | 7287 |
| Max. digging depth | mm | 7423 |
| Max. digging depth of cut for | mm | 7266| Model | Unit | XE370C | | Operating weight | kg | 36400 | | Standard bucket capacity | m³ | 1.4 ~ 1.8 |
| Model Engine Model | / | ISUZU AA-6HK1XQP | | Direct injection | / | √ | | Four strokes | / | √ | | Water cooling | / | √ | | Turbo charged | / | √ | | Air to air intercooler | / | √ | | No. of cylinders | / | 6 | | Rated power/speed | kw/rpm | 184/2000 | | Max. torque/speed | N.m | 872.8/2000 | | Displacement | L | 7.79 | | Main performance | Travel speed | km/h | 5.4/3.2 | | Swing speed | r/min | 9.7 | | Max. gradeability | / | ≥35 | | Ground pressure | kPa | 65.7 | | Max.Bucket digging force | kN | 242 | | Max.arm crowd force | kN | 183 | | Max.traction force | kN | 285 | | hydraulic system | Main pump | / | 2 | | Rate flow of main pump | L/min | 2×280 | | Max pressure of prime relief valve | MPa | 31.5/34.3 | | Max pressure of travel system | MPa | 34.3 | | Max pressure of swing system | MPa | 27.5 | | Max pressure of pilot system | MPa | 3.9 | | Fuel | Fuel tank capacity | L | 630 | | Hydraulic tank capacity | L | 320 | | Engine lubrication | L | 28 | | Dimension | A: Overall length | mm | 11246 | | B: Overall width | mm | 3190 | | C: Overall height | mm | 3350 | | D: Overall width of upperstructure | mm | 2960 | | E: Track length | mm | 5035 | | F: Overall width of undercarriage | mm | 3190 | | G: Crawler width | mm | 600 | | H: Track length on ground | mm | 4040 | | I: Crawler gauge | mm | 2590 | | J: Clearance under counter weight | mm | 1197 | | K: Ground clearance | mm | 500 | | L: Min.tail swing radius | mm | 3450 | | Working range | A: Max. digging height | mm | 10423 | | B: Max. dumping height | mm | 7275 | | C: Max. digging depth | mm | 7139 | | D:8inch horizonal digging depth | mm | 6954 | | E: Max. vertical wall digging depth | mm | 6545 | | F: Max. digging reach | mm | 10887 | | G: Min. swing radius | mm | 4424 | | Angle of arm deflection | Degree |
|
|
