Product Specifications
| Prod Model: |
TPS-BANTE820 series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
AUTOMATIC CALIBRATION:
The meters can be calibrated at one or two points - in air (100%) and/or with a zero oxygen solution, easy and Quick calibration ensures accurate reading.
AUTO-CALIBRATION RECOGNITION:
During calibration, if the calibration condition does not Match the meter's requirement, an ERROR message is Displayed.
AUTOMATIC TEMPERATURE COMPENSATION:
The DO probe with a globular shape temperature sensor, It can provides automatic temperature compensation to Ensure accurate measuring value
SPECIFICATIONS:
SALINITY AND BAROMETRIC PRESSURE COMPENSATION:
Salt dissolved in solution limits oxygen content, BANTE 8 Series meters can compensates salinity and barometric Pressure after manual input coefficients.
MULTI-MEASUREMENT UNITS:
The meters can choose the various units for different Countries. Example: Mg/L vs. Ppm; KPa vs. MmHg. Degrees. C vs. F, and so on.
HOLD FUNCTION:
To keep the latest measurement on the display, after taking A reading press the HOLD key and the measurement remains On the display, You can easily view and record data.
POWER MONITOR:
During using, The CPU continuously monitors and displays The battery level, When the battery is running out of power, The battery icon will disappear from the LCD.
MESSAGE INDICATOR:
The meters displays helpful messages like an on-screen Manual for easy operation of this meter and choosing of the Various functions and options.
SAVE AND COMMUNICATION INTERFACE:
BANTE 8 series all have real-time date / clock stamps, The Memory stores up to 48 discrete data sets. Press the SAVE To store the current measured values and it automatically Generates a serial number with the date and time. This data Can then be sent to a computer via the USB port.
|
Model |
|
BANTE820 |
|
BANTE821 |
|
|
Dissolved Oxygen Range |
|
0.0 ~20.0mg/L or ppm |
|
0.00 ~20.00mg/L or ppm |
|
|
Resolution |
|
0.1mg/L |
|
0.01mg/L |
|
|
Dissolved Oxygen Accuracy |
|
± 0.5mg/L |
|
± 0.3mg/L |
|
|
% Saturation of Oxygen |
|
0.0 ~200.0% |
|
0.0 ~200.0% |
|
|
Accuracy |
|
± 10.00% |
|
± 5.00% |
|
|
Temperature Range |
|
0.0~50.0 o C, 32~122 o F |
|
|
Temperature Accuracy |
|
± 1 o C, ± 1.8 o F |
|
|
Temperature Compensation |
|
0.0~40.0 o C, Automatic |
|
|
Salinity Correction |
|
0~35 g/L |
|
|
Barometric Pressure Correction |
|
450~850 mmHg, 60.0~112.5kPa |
|
|
Calibration Points |
|
1 or 2 points, 100% in air or 0% in solution |
|
|
Memory |
|
48 data sets with Date/Time stamping |
|
|
Output |
|
USB communication interface |
|
|
Power Requirements |
|
9V battery |
|
|
Dimensions |
|
185(L)× 88(W)× 32(H)mm |
|
|
Weight |
|
300g |
