Product Specifications
| Prod Model: |
PDJ-3000H |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Parameters: |
6 Parameters |
| LCD Display: |
12.1"High Brightness TFT LCD |
| Option: |
IBP, Etco2 and 2-IBP |
| Capacity Of Built-in Rechargeable Batter: |
2 Hours Working |
| Type: |
Patient/Fetal/Maternal Monitor |
| Classification: |
Physiological Functions of Diagnosis and Monitoring Equipment |
Product Description
Portable Infant/Emergency Multi-parameter Patient Monitor PDJ-3000H
Features:
1. Displayer: 8.4" color TFT LCD screen with maximum 7-waveform display.
2. Battery: Rechargeable high-energy built-in battery can be used around 3 hours after fully charged
3. Advanced streamline outline design, portable, compact, lightweight
4. Operating menu with multi-language interface selection: English, Spanish, Portuguese, Chinese, Arabic, Russian, Italian, etc.
5. Easy operation with user friendly menu structure design and rotary dial
6. Against & eliminate ESU interference & defibrillation, no need to disconnect the monitor from the patient in process of defibrillating.
7. Three-application mode: Monitoring, diagnosis, operating.
8. WAN communication function to network with central monitoring system and make long-distance monitoring, diagnosis, maintenance and software upgrade possible
9. Optional built-in wireless networking function
10.360 hours data storage.
|
Specifications: |
|
Temperature (surface and rectal) |
|
Measurement range: 0 – 50.0 degree |
|
Accuracy: ± 0.1degree |
|
Resolution: 0.1 degree |
|
response time: ≤ 3 min. |
|
|
|
ECG |
|
Input: 5 wires ECG cable |
|
Lead section:I,II,III/ aVR, aVL, aVF/ V |
|
Gain(mm/mV): 1/4,1/2,1,2,4 |
|
Frequency response: Diagnosis 0.05 - 100Hz |
|
Monitor 0.5 - 40 Hz |
|
Surgery 1.0 - 25 Hz |
|
Sweep speed(mm/sec): 3.125,6.25,12.5, 25, 50 |
|
Heart rate range: 30-254 BPM |
|
Heart rate accuracy: ± 1 % |
|
ST segment deviation analysis: -0.8-+0.8mV |
|
ST accuracy: ±0.02mv |
|
|
|
Respiration Rate(RA-LL impedance and nasal cavity) |
|
Measurement range: 0 - 156 BPM(adult) |
|
Accuracy: ± 1 BPM or 5 % |
|
Resolution: 1 BPM |
|
|
|
Pulse Rate |
|
SPO2 measurement range: 0 - 100 % |
|
Resolution: 1 % |
|
Pulse measurement range: 30- 254BPM |
|
Accuracy: ± 2 % |
|
Resolution: 1 BPM |
|
|
|
NIBP (Non-invasive blood pressure) |
|
Measurement type : adult, pediatric, neonatal |
|
Measurement range: Systolic 4.0 - 37.0 kPa |
|
Diastolic 1.3 - 33.0 kPa |
|
Mean 2.6 - 35.0 kPa |
|
Accuracy : ± 0.4 kPa or 5 % |
|
Resolution: 0.1 kPa |
|
Protection: over pressure |
|
|
|
IBP(Invasive blood pressure) (with venous punch) |
|
(Option) |
|
Measurement range: -1.3~40kPa (-10~300mmHg) |
|
Channel: 2 channel |
|
Transducer sensitivity: 5MV/V/mmHg |
|
Unit display: KPa or mmHg selectable |
|
|
|
Power requirements |
|
Input: 98~260 V AC, 50/60Hz |
|
Consumption: ≤ 80VA |
Perlong Medical Equipment Co., Ltd., was founded in Nanjing in 2003, headquartered in Nanjing, Perlong is not only one of the largest manufacturers and exporters of medical equipment in China, but also an integrated supplier of complete medical equipment Diagnosis and Treatment Solution.
After five years of growing, the sister company of Perlong was founded in 2008 for more business expansion. The new company was named Seeuco Electronics Technology Co., Ltd. Both Perlong and Seeuco are doing the same business of exporting medical equipment.
As the leading professional manufacturer & exporter of medical equipment, we have our own factories, and also have established long-term cooperation with many famous manufacturers in China. We mainly supply basic medical equipments for all types of hospitals and clinics. Help our customers to design and improve their programs.
Our superior products are: Surgical equipment, clinical lab equipments, various reagents, X-ray series, ultrasound scanner, ECG and so on. Our products have excellent performance, reliable quality, good cost effective, and have perfect after service. All the products have been certified by FDA China, and most of them have passed CE certificate audit.
With idea of "Faith-based, customer-orientated, innovative and pragmatic, quality and efficient", we have established our efficient worldwide network of marketing. In the past years, we have exported our products to more than 130 countries all over the world. We also have established long-term cooperation with WHO, UNICEF and many other international organizations. We have won good reputation in the whole medical field all over the world.
We have an excellent team of researchers and sales persons, so we can provide good equipments and perfect technical support. Your cooperation with us will definitely create a win-win situation for both of us.
