Product Specifications
Product Description
MemoryFlash 1G X 1
SDRAM 256MB X 1
Sliding SwitchROUTER mode
Device will enable 3G-WiFi router function.
MODEM mode
Device will be a dedicated 3G USB dongle.
LED IndicationPower / Signal / Battery / Wi-Fi / SMS indicator
InterfaceSupporting 3V/1.8V 6pin standard uim card
Supporting USB 2.0 high speed(support charging)
One Internal 3G main antenna, One Internal 3G diversity antenna, One WiFi antenna
EVDO Module
SolutionEVDO Rev. A
BandDual band: 800/1900MHz
Data speedDownlink up to 3.1Mbps; Uplink up to 1.8Mbps
Dimension30X 51X4.6 mm
RF Specification
Cellular Band RX
Frequency range869MHz~894MHz
Sensitivity-105.5dBm(FER≤ 0.5%)
Dynamic range-25~-105.5dBm(FER≤ 0.5%)
Single tone Desensitization-102.4dBm(FER≤ 1%, -30dBm@± 900kHz)
Intermediation Spurious Response Attenuation-102.4dBm(FER≤ 1%, -43dBm@± 900 kHz/± 1700kHz)
-91.4dBm(FER≤ 1%, -32dBm @± 900 kHz/± 1700kHz)
-80.4dBm(FER≤ 1%, -21dBm @± 900 kHz/± 1700kHz)
Conducted Spurious Emission<-76dBm/1MHz(RX band)
<-61dBm/1MHz( TX band)
<-47dBm/30kHz(other frequency)
MemoryFlash 1G X 1
SDRAM 256MB X 1
Sliding SwitchROUTER mode
Device will enable 3G-WiFi router function.
MODEM mode
Device will be a dedicated 3G USB dongle.
LED IndicationPower / Signal / Battery / Wi-Fi / SMS indicator
InterfaceSupporting 3V/1.8V 6pin standard uim card
Supporting USB 2.0 high speed(support charging)
One Internal 3G main antenna, One Internal 3G diversity antenna, One WiFi antenna
EVDO Module
SolutionEVDO Rev. A
BandDual band: 800/1900MHz
Data speedDownlink up to 3.1Mbps; Uplink up to 1.8Mbps
Dimension30X 51X4.6 mm
RF Specification
Cellular Band RX
Frequency range869MHz~894MHz
Sensitivity-105.5dBm(FER≤ 0.5%)
Dynamic range-25~-105.5dBm(FER≤ 0.5%)
Single tone Desensitization-102.4dBm(FER≤ 1%, -30dBm@± 900kHz)
Intermediation Spurious Response Attenuation-102.4dBm(FER≤ 1%, -43dBm@± 900 kHz/± 1700kHz)
-91.4dBm(FER≤ 1%, -32dBm @± 900 kHz/± 1700kHz)
-80.4dBm(FER≤ 1%, -21dBm @± 900 kHz/± 1700kHz)
Conducted Spurious Emission<-76dBm/1MHz(RX band)
<-61dBm/1MHz( TX band)
<-47dBm/30kHz(other frequency)
